Table 3-14. HPI Terminal Functions (continued)
SIGNAL
TYPE
(1)
OTHER
(2) (3)
DESCRIPTION
NAME NO.
PCI_AD23/
DD7/ B5
HD23/EM_A[7]
PCI_AD22/
DD6/ C7
HD22/EM_A[6]
PCI_AD21/
DD5/ C5
HD21/EM_A[5]
PCI_AD20/
DD4/ D7
These pins are multiplexed between PCI, ATA, HPI, and EMIFA.
HD20/EM_A[4]
IPD
I/O/Z In HPI-32 mode, these pins are the HPI upper data bus, HD[31:16] (I/O/Z).
DV
DD33
PCI_AD19/
In HPI-16 mode, the HD[31:16] pins are not used by the HPI .
DD3/ A4
HD19/EM_A[3]
PCI_AD18/
DD2/ E7
HD18/EM_A[2]
PCI_AD17/
DD1/ B4
HD17/EM_A[1]
PCI_AD16/
DD0/ C6
HD16/EM_A[0]
PCI_AD15/
E5
HD15/EM_D15
PCI_AD14/
C1
HD14/EM_D14
PCI_AD13/
E4
HD13/EM_D13
PCI_AD12/
D3
These pins are multiplexed between PCI, HPI, and EMIFA.
HD12/EM_D12
IPD
I/O/Z In HPI-16 mode, these pins are the HPI data bus, HD[15:0] (I/O/Z).
DV
DD33
PCI_AD11/
In HPI-32 mode, these pins are the HPI lower data bus, HD[15:0] (I/O/Z).
E3
HD11/EM_D11
PCI_AD10/
D2
HD10/EM_D10
PCI_AD9/
F5
HD9/EM_D9
PCI_AD8/
D1
HD8/EM_D8
PCI_AD7/
E2
HD7/EM_D7
PCI_AD6/
F3
HD6/EM_D6
PCI_AD5/
E1
HD5/EM_D5
PCI_AD4/
G5
These pins are multiplexed between PCI, HPI, and EMIFA.
HD4/EM_D4
IPD
I/O/Z In HPI-16 mode, these pins are the HPI data bus, HD[15:0] (I/O/Z).
DV
DD33
PCI_AD3/
In HPI-32 mode, these pins are the HPI lower data bus, HD[15:0] (I/O/Z).
F2
HD3/EM_D3
PCI_AD2/
G4
HD2/EM_D2
PCI_AD1/
F1
HD1/EM_D1
PCI_AD0/
G3
HD0/EM_D0
