Table 3-13. VLYNQ Terminal Functions
SIGNAL
TYPE
(1)
OTHER
(2) (3)
DESCRIPTION
NAME NO.
VLYNQ
IPU
VLYNQ_CLOCK U1 I/O/Z VLYNQ serial clock
DV
DD33
IPU
VLYNQ_SCRUN U2 I/O/Z VLYNQ serial clock run request
DV
DD33
VLYNQ_TXD3 T3
VLYNQ_TXD2 T2
–
O/Z VLYNQ transmit bus [3:0]
DV
DD33
VLYNQ_TXD1 T1
VLYNQ_TXD0 R4
VLYNQ_RXD3 R3
VLYNQ_RXD2 R2
IPD
I VLYNQ receive bus [3:0]
DV
DD33
VLYNQ_RXD1 P3
VLYNQ_RXD0 P4
(1) I = Input, O = Output, Z = High impedance, S = Supply voltage, GND = Ground, A = Analog signal
(2) IPD = Internal pulldown, IPU = Internal pullup. For more detailed information on pullup/pulldown resistors and situations where external
pullup/pulldown resistors are required, see Section 4.8.1, Pullup/Pulldown Resistors.
(3) Specifies the operating I/O supply voltage for each signal
