TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 3-11. Peripheral Component Interconnect (PCI) Terminal Functions (continued)
SIGNAL
TYPE
(1)
OTHER
(2) (3)
DESCRIPTION
NAME NO.
PCI_AD7/ [IPD]
E2 I/O/Z
HD7/EM_D7 DV
DD33
PCI_AD6/ [IPD]
F3 I/O/Z
HD6/EM_D6 DV
DD33
PCI_AD5/ [IPD]
E1 I/O/Z
HD5/EM_D5 DV
DD33
PCI_AD4/ [IPD]
G5 I/O/Z
HD4/EM_D4 DV
DD33
These pins are multiplexed between PCI, HPI, and EMIFA.
For PCI, these pins are PCI data/address bus [15:0] (I/O/Z)
PCI_AD3/ [IPD]
F2 I/O/Z
HD3/EM_D3 DV
DD33
PCI_AD2/ [IPD]
G4 I/O/Z
HD2/EM_D2 DV
DD33
PCI_AD1/ [IPD]
F1 I/O/Z
HD1/EM_D1 DV
DD33
PCI_AD0/ [IPD]
G3 I/O/Z
HD0/EM_D0 DV
DD33
PCI_RSV0/DA1/ [IPD]
A9 I/O/Z PCI reserved (I)
(1)
GP[16]/EM_A[21] DV
DD33
PCI_RSV1/DA0/ [IPD]
E9 I/O/Z PCI reserved (O/Z)
(1)
GP[17]/EM_A[20] DV
DD33
PCI_RSV2/INTRQ/ [IPD]
B10 I/O/Z PCI reserved (I)
(1)
GP[18]/EM_RSV 0 DV
DD33
PCI_RSV3/DIOR/
[IPU]
GP[19]/ E10 I/O/Z PCI reserved (O/Z)
(1)
DV
DD33
EM_WAIT5
PCI_RSV4/DIOW/
[IPU]
GP[20]/ A11 I/O/Z PCI reserved (I/O/Z)
(1)
DV
DD33
EM_WAIT4
PCI_RSV5/IORDY/
[IPU]
GP[21]/ D11 I/O/Z PCI reserved (I/O/Z)
(1)
DV
DD33
EM_WAIT3
(1) In PCI mode (PCIEN = 1), it is recommended to have an external pullup resistor on this pin.
44 Device Overview Copyright © 2009–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
