TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 3-11. Peripheral Component Interconnect (PCI) Terminal Functions (continued)
SIGNAL
TYPE
(1)
OTHER
(2) (3)
DESCRIPTION
NAME NO.
PCI_AD31/DD15/ [IPD]
A8 I/O/Z
HD31/EM_A[15] DV
DD33
PCI_AD30/DD14/ [IPD]
C9 I/O/Z
HD30/EM_A[14] DV
DD33
PCI_AD29/DD13/ [IPD]
B8 I/O/Z
HD29/EM_A[13] DV
DD33
PCI_AD28/DD12/ [IPD]
D9 I/O/Z
HD28/EM_A[12] DV
DD33
PCI_AD27/DD11/ [IPD]
A6 I/O/Z
HD27/EM_A[11] DV
DD33
PCI_AD26/DD10/ [IPD]
C8 I/O/Z
HD26/EM_A[10] DV
DD33
PCI_AD25/DD9/ [IPD]
B6 I/O/Z
HD25/EM_A[9] DV
DD33
PCI_AD24/DD8/ [IPD]
D8 I/O/Z
These pins are multiplexed between PCI, ATA, HPI, and EMIFA.
HD24/EM_A[8] DV
DD33
In PCI mode, these pins are the PCI address/data bus, PCI_AD[31:16]
PCI_AD23/DD7/ [IPD]
(I/O/Z).
B5 I/O/Z
HD23/EM_A[7] DV
DD33
PCI_AD22/DD6/ [IPD]
C7 I/O/Z
HD22/EM_A[6] DV
DD33
PCI_AD21/DD5/ [IPD]
C5 I/O/Z
HD21/EM_A[5] DV
DD33
PCI_AD20/DD4/ [IPD]
D7 I/O/Z
HD20/EM_A[4] DV
DD33
PCI_AD19/DD3/ [IPD]
A4 I/O/Z
HD19/EM_A[3] DV
DD33
PCI_AD18/DD2/ [IPU]
E7 I/O/Z
HD18/EM_A[2] DV
DD33
PCI_AD17/DD1/ [IPD]
B4 I/O/Z
HD17/EM_A[1] DV
DD33
PCI_AD16/DD0/ [IPD]
C6 I/O/Z
HD16/EM_A[0] DV
DD33
PCI_AD15/ [IPD]
E5 I/O/Z
HD15/EM_D15 DV
DD33
PCI_AD14/ [IPD]
C1 I/O/Z
HD14/EM_D14 DV
DD33
PCI_AD13/ [IPD]
E4 I/O/Z
HD13/EM_D13 DV
DD33
PCI_AD12/ [IPD]
D3 I/O/Z
HD12/EM_D12 DV
DD33
These pins are multiplexed between PCI, HPI, and EMIFA.
For PCI, these pins are PCI data/address bus, PCI_AD [15:0] (I/O/Z).
PCI_AD11/ [IPD]
E3 I/O/Z
HD11/EM_D11 DV
DD33
PCI_AD10/ [IPD]
D2 I/O/Z
HD10/EM_D10 DV
DD33
PCI_AD9/ [IPU]
F5 I/O/Z
HD9/EM_D9 DV
DD33
PCI_AD8/ [IPD]
D1 I/O/Z
HD8/EM_D8 DV
DD33
Copyright © 2009–2012, Texas Instruments Incorporated Device Overview 43
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
