TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 3-10. DDR2 Memory Controller Terminal Functions (continued)
SIGNAL
TYPE
(1)
OTHER
(2) (3)
DESCRIPTION
NAME NO.
DDR_D[31] Y20
DDR_D[30] W20
DDR_D[29] Y21
DDR_D[28] AA21
DDR_D[27] U21
DDR_D[26] T21
DDR_D[25] R20
DDR_D[24] T20
DDR_D[23] AB22
DDR_D[22] Y22
DDR_D[21] AA22
DDR_D[20] AA23
DDR_D[19] V23
DDR_D[18] U23
DDR_D[17] T22
DDR_D[16] U22
I/O/Z DV
DDR2
DDR2 data bus can be configured as 32 bits wide or 16 bits wide.
DDR_D[15] H22
DDR_D[14] G23
DDR_D[13] G22
DDR_D[12] F23
DDR_D[11] E23
DDR_D[10] C22
DDR_D[9] B22
DDR_D[8] C23
DDR_D[7] H20
DDR_D[6] G21
DDR_D[5] F21
DDR_D[4] G20
DDR_D[3] B21
DDR_D[2] C20
DDR_D[1] D20
DDR_D[0] C21
DDR_DQGATE0 J19 O/Z DV
DDR2
DDR2 strobe gate signal for lower-half data bus
DDR_DQGATE1 J21 I DV
DDR2
DDR2 strobe gate signal return for lower-half data bus
DDR_DQGATE2 R19 O/Z DV
DDR2
DDR2 strobe gate signal for upper-half data bus
DDR_DQGATE3 R21 I DV
DDR2
DDR2 strobe gate signal return for upper-half data bus
DDR_VREF P23 S
(4)
Reference voltage input for the SSTL_18 IO buffers.
Impedance control for DDR2 outputs. This must be connected via a 50-Ω (±5%
DDR_ZP L19 O
(4)
tolerance) resistor to V
SS
.
Impedance control for DDR2 outputs. This must be connected via a 50-Ω (±5%
DDR_ZN M19 O
(4)
tolerance) resistor to DV
DDR2
.
(4) For more information, see the Recommended Operating Conditions table
