TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 3-10. DDR2 Memory Controller Terminal Functions
SIGNAL
TYPE
(1)
OTHER
(2) (3)
DESCRIPTION
NAME NO.
DDR2 Memory Controller
DDR_CLK M23 O/Z DV
DDR2
DDR2 Clock
DDR_CLK L23 O/Z DV
DDR2
DDR2 Differential clock
DDR_CKE M20 O/Z DV
DDR2
DDR2 Clock Enable
DDR_CS J20 O/Z DV
DDR2
DDR2 Active low chip select
DDR_WE L20 O/Z DV
DDR2
DDR2 Active low Write enable
DDR_RAS K19 O/Z DV
DDR2
DDR2 Row Access Signal output
DDR_CAS L21 O/Z DV
DDR2
DDR2 Column Access Signal output
DDR_DQM[3] V20 O/Z DV
DDR2
DDR2 Data mask outputs
DDR_DQM[3]: For upper byte data bus DDR_D[31:24]
DDR_DQM[2] Y23 O/Z DV
DDR2
DDR_DQM[2]: For DDR_D[23:16]
DDR_DQM[1] F22 O/Z DV
DDR2
DDR_DQM[1]: For DDR_D[15:8]
DDR_DQM[0]: For lower byte DDR_D[7:0]
DDR_DQM[0] F20 O/Z DV
DDR2
DDR_DQS[3] U20 I/O/Z DV
DDR2
Data strobe input/outputs for each byte of the 32-bit data bus. They are outputs to
the DDR2 memory when writing and inputs when reading. They are used to
DDR_DQS[2] V22 I/O/Z DV
DDR2
synchronize the data transfers.
DDR_DQS[1] D22 I/O/Z DV
DDR2
DDR_DQS[3] : For upper byte DDR_D[31:24]
DDR_DQS[2]: For DDR_D[23:16]
DDR_DQS[1]: For DDR_D[15:8]
DDR_DQS[0] D21 I/O/Z DV
DDR2
DDR_DQS[0]: For bottom byte DDR_D[7:0]
DDR_DQS[3] V21 I/O/Z DV
DDR2
Complimentary data strobe input/outputs for each byte of the 32-bit data bus. They
are outputs to the DDR2 memory when writing and inputs when reading. They are
DDR_DQS[2] W23 I/O/Z DV
DDR2
used to synchronize the data transfers.
DDR_DQS[1] D23 I/O/Z DV
DDR2
DDR_DQS[3] : For upper byte DDR_D[31:24]
DDR_DQS[2]: For DDR_D[23:16]
DDR_DQS[1]: For DDR_D[15:8]
DDR_DQS[0] E20 I/O/Z DV
DDR2
DDR_DQS[0]: For bottom byte DDR_D[7:0]
DDR_ODT0 K20 O/Z DV
DDR2
DDR2 on-die termination control
DDR_BA[2] P19
DDR_BA[1] M21 O/Z DV
DDR2
Bank address outputs (BA[2:0]).
DDR_BA[0] N19
DDR_A[14] N23
DDR_A[13] H21
DDR_A[12] P20
DDR_A[11] K23
DDR_A[10] T23
DDR_A[9] N22
DDR_A[8] J23
DDR_A[7] N20 O/Z DV
DDR2
DDR2 address bus
DDR_A[6] M22
DDR_A[5] N21
DDR_A[4] J22
DDR_A[3] R22
DDR_A[2] L22
DDR_A[1] R23
DDR_A[0] H23
(1) I = Input, O = Output, Z = High impedance, S = Supply voltage, GND = Ground, A = Analog signal
(2) Specifies the operating I/O supply voltage for each signal
(3) For more information, see the Recommended Operating Conditions table
