TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 3-9. Asynchronous External Memory Interface (EMIFA) Terminal Functions (continued)
SIGNAL
TYPE
(1)
OTHER
(2) (3)
DESCRIPTION
NAME NO.
PCI_AD24/ This pin is multiplexed between PCI, ATA, HPI, and EMIFA.
IPD
DD8/ D8 I/O/Z For EMIFA, this pin is address bit 8 output EM_A[8] (O/Z).
DV
DD33
HD24/EM_A[8] This signal is not available when ATA is enabled (i.e., EMIF NAND Flash mode).
PCI_AD23/ This pin is multiplexed between PCI, ATA, HPI, and EMIFA.
IPD
DD7/ B5 I/O/Z For EMIFA, this pin is address bit 7 output EM_A[7] (O/Z).
DV
DD33
HD23/EM_A[7] This signal is not available when ATA is enabled (i.e., EMIF NAND Flash mode).
PCI_AD22/ This pin is multiplexed between PCI, ATA, HPI, and EMIFA.
IPD
DD6/ C7 I/O/Z For EMIFA, this pin is address bit 6 output EM_A[6] (O/Z).
DV
DD33
HD22/EM_A[6] This signal is not available when ATA is enabled (i.e., EMIF NAND Flash mode).
PCI_AD21/ This pin is multiplexed between PCI, ATA, HPI, and EMIFA.
IPD
DD5/ C5 I/O/Z For EMIFA, this pin is address bit 5 output EM_A[5] (O/Z).
DV
DD33
HD21/EM_A[5] This signal is not available when ATA is enabled (i.e., EMIF NAND Flash mode).
PCI_AD20/ This pin is multiplexed between PCI, ATA, HPI, and EMIFA.
IPD
DD4/ D7 I/O/Z For EMIFA, this pin is address bit 4 output EM_A[4] (O/Z).
DV
DD33
HD20/EM_A[4] This signal is not available when ATA is enabled (i.e., EMIF NAND Flash mode).
PCI_AD19/ This pin is multiplexed between PCI, ATA, HPI, and EMIFA.
IPD
DD3/ A4 I/O/Z For EMIFA, this pin is address bit 3 output EM_A[3] (O/Z).
DV
DD33
HD19/EM_A[3] This signal is not available when ATA is enabled (i.e., EMIF NAND Flash mode).
PCI_AD18/ This pin is multiplexed between PCI, ATA, HPI, and EMIFA.
IPD
DD2/ E7 I/O/Z For EMIFA, this pin is address bit 2 output EM_A[2] (O/Z).
DV
DD33
HD18/EM_A[2] This signal is not available when ATA is enabled (i.e., EMIF NAND Flash mode).
PCI_AD17/ This pin is multiplexed between PCI, ATA, HPI, and EMIFA.
IPD
DD1/ B4 I/O/Z For EMIFA, this pin is address bit 1 output EM_A[1] (O/Z).
DV
DD33
HD17/EM_A[1] This signal is not available when ATA is enabled (i.e., EMIF NAND Flash mode).
This pin is multiplexed between PCI, ATA, HPI, and EMIFA.
For EMIFA, this pin is address bit 0 output EM_A[0] (O/Z), which is the least
PCI_AD16/
IPD significant bit on a 32-bit word address.
DD0/ C6 I/O/Z
DV
DD33
When connected to a 16-bit asynchronous memory, this pin is the second bit of
HD16/EM_A[0]
the address.
For an 8-bit asynchronous memory, this pin is the third bit of the address.
