TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 7-140. Timer 1 Registers
HEX ADDRESS RANGE ACRONYM DESCRIPTION
0x01C2 1800 PID12 Timer 1 Peripheral Identification Register 12
0x01C2 1804 EMUMGT Timer 1 Emulation Management
0x01C2 1810 TIM12 Timer 1 Counter Register 12
0x01C2 1814 TIM34 Timer 1 Counter Register 34
0x01C2 1818 PRD12 Timer 1 Period Register 12
0x01C2 181C PRD34 Timer 1 Period Register 34
0x01C2 1820 TCR Timer 1 Control Register
0x01C2 1824 TGCR Timer 1 Global Control Register
0x01C2 1828 - 0x01C2 1BFF - Reserved
Table 7-141. Timer 2 (Watchdog) Registers
HEX ADDRESS RANGE ACRONYM DESCRIPTION
0x01C2 1C00 PID12 Timer 2 Peripheral Identification Register 12
0x01C2 1C04 EMUMGT Timer 2 Emulation Management
0x01C2 1C10 TIM12 Timer 2 Counter Register 12
0x01C2 1C14 TIM34 Timer 2 Counter Register 34
0x01C2 1C18 PRD12 Timer 2 Period Register 12
0x01C2 1C1C PRD34 Timer 2 Period Register 34
0x01C2 1C20 TCR Timer 2 Control Register
0x01C2 1C24 TGCR Timer 2 Global Control Register
0x01C2 1C28 WDTCR Timer 2 Watchdog Timer Control Register
0x01C2 1C2C - 0x01C2 1FFF - Reserved
