TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
7.27 Timers
The timers support four modes of operation: a 64-bit general-purpose (GP) timer, dual-unchained 32-bit
GP timers, dual-chained 32-bit timers, or a watchdog timer. The GP timer mode can be used to generate
periodic interrupts or EDMA synchronization events. The watchdog timer mode is used to provide a
recovery mechanism for the device in the event of a fault condition, such as a non-exiting code loop.
7.27.1 Timers Device-Specific Information
The DM6467T device has 3 64-bit general-purpose timers which have the following features:
• 64-bit count-up counter
• Timer modes:
– 64-bit general-purpose timer mode (Timer 0 and 1)
– Dual 32-bit general-purpose timer mode (Timer 0 and 1)
– Watchdog timer mode (Timer 2) [mainly controlled by the ARM]
• 2 possible clock sources:
– Internal clock
– External clock input via timer input pin TINP0U, TINP0L, and TINP1L, (Timer 0 and 1 only)
• 2 operation modes:
– One-time operation (timer runs for one period then stops)
– Continuous operation (timer automatically resets after each period)
• Generates interrupts to the DSP and the ARM CPUs
• Generates sync event to EDMA
• Causes device global reset upon watchdog timer timeout (Timer 2 only)
For more detailed information, see the TMS320DM646x DMSoC 64-Bit Timer User's Guide (literature
number SPRUER5).
7.27.2 Timer Peripheral Register Description(s)
Table 7-139, Table 7-140, and Table 7-141 show the registers for Timer 0, Timer 1, and Timer 2
(Watchdog).
Table 7-139. Timer 0 Registers
HEX ADDRESS RANGE ACRONYM DESCRIPTION
0x01C2 1400 PID12 Timer 0 Peripheral Identification Register 12
0x01C2 1404 EMUMGT Timer 0 Emulation Management
0x01C2 1410 TIM12 Timer 0 Counter Register 12
0x01C2 1414 TIM34 Timer 0 Counter Register 34
0x01C2 1418 PRD12 Timer 0 Period Register 12
0x01C2 141C PRD34 Timer 0 Period Register 34
0x01C2 1420 TCR Timer 0 Control Register
0x01C2 1424 TGCR Timer 0 Global Control Register
0x01C2 1428 - 0x01C2 17FF - Reserved
