25
23
19
18
22
27
20
21
17
18
28
Stop Start Repeated
Start
Stop
SDA
SCL
16
26 24
TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 7-135. Switching Characteristics for I2C Timings
(1)
(see Figure 7-90)
-1G
STANDARD
NO. PARAMETER FAST MODE UNIT
MODE
MIN MAX MIN MAX
16 t
c(SCL)
Cycle time, SCL 10 2.5 µs
Delay time, SCL high to SDA low (for a repeated START
17 t
d(SCLH-SDAL)
4.7 0.6 µs
condition)
Delay time, SDA low to SCL low (for a START and a repeated
18 t
d(SDAL-SCLL)
4 0.6 µs
START condition)
19 t
w(SCLL)
Pulse duration, SCL low 4.7 1.3 µs
20 t
w(SCLH)
Pulse duration, SCL high 4 0.6 µs
21 t
d(SDAV-SCLH)
Delay time, SDA valid to SCL high 250 100 ns
22 t
v(SCLL-SDAV)
Valid time, SDA valid after SCL low 0 0 0.9 µs
Pulse duration, SDA high between STOP and START
23 t
w(SDAH)
4.7 1.3 µs
conditions
20 + 0.1C
b
24 t
r(SDA)
Rise time, SDA 1000 300 ns
(2)
20 + 0.1C
b
25 t
r(SCL)
Rise time, SCL 1000 300 ns
(2)
20 + 0.1C
b
26 t
f(SDA)
Fall time, SDA 300 300 ns
(2)
20 + 0.1C
b
27 t
f(SCL)
Fall time, SCL 300 300 ns
(2)
28 t
d(SCLH-SDAH)
Delay time, SCL high to SDA high (for STOP condition) 4 0.6 µs
29 C
p
Capacitance for each I2C pin 10 10 pF
(1) C
b
= total capacitance of one bus line in pF. If mixed with HS-mode devices, faster fall-times are allowed.
(2) C
b
= total capacitance of one bus line in pF. If mixed with HS-mode devices, faster fall-times are allowed.
Figure 7-90. I2C Transmit Timings
