TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
7.24.4 IrDA Interface Receive/Transmit Timings
Table 7-130. Signaling Rate and Pulse Duration Specification in Receive Mode
ELECTRICAL PULSE DURATION
SIGNALING RATE UNIT
MAX NOM MIN
SIR MODE
2.4 Kbit/s (Kbps) 1.41 78.1 88.55 μs
9.6 Kbps 1.41 19.5 22.13 μs
19.2 Kbps 1.41 9.75 11.07 μs
38.4 Kbps 1.41 4.87 5.96 μs
57.6 Kbps 1.41 3.25 4.34 μs
115.2 Kbps 1.41 1.62 2.23 μs
MIR MODE
0.576 Mbit/s (Mbps) 297.2 416 518.8 ns
Table 7-131. Timing Requirements for IrDA Receive
-1G
NO. UNIT
MIN MAX
1 t
r(URXD)
Rise time, receive data bit URXDx 200 ns
2 t
f(URXD)
Fall time, receive data bit URXDx 200 ns
Table 7-132. Signaling Rate and Pulse Duration Specification in Transmit Mode
ELECTRICAL PULSE DURATION
SIGNALING RATE UNIT
MAX NOM MIN
SIR MODE
2.4 Kbit/s (Kbps) 78.10 78.1 78.10 μs
9.6 Kbps 19.50 19.5 19.50 μs
19.2 Kbps 9.75 9.75 9.75 μs
38.4 Kbps 4.87 4.87 4.87 μs
57.6 Kbps 3.25 3.25 3.25 μs
115.2 Kbps 1.62 1.62 1.62 μs
MIR MODE
0.576 Mbit/s (Mbps) 414.0 416.0 419.0 ns
332 Peripheral Information and Electrical Specifications Copyright © 2009–2012, Texas Instruments Incorporated
