TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 7-126. UART1 – UART/IrDA/CIR Register Program Map
HEX ADDRESS REGISTER
RANGE
LCR[7] = 0 LCR[7] = 1 & LCR[7:0] ≠ 0xBF LCR[7:0] = 0xBF
READ WRITE READ WRITE READ WRITE
0x01C2 0400 RHR THR DLL DLL DLL DLL
0x01C2 0404 IER
(1)
IER
(1)
DLH DLH DLH DLH
0x01C2 0408 IIR FCR
(2)
IIR FCR
(2)
EFR EFR
0x01C2 040C LCR LCR LCR LCR LCR LCR
0x01C2 0410 MCR
(2)
MCR
(2)
MCR
(2)
MCR
(2)
XON1/ADDR1 XON1/ADDR1
0x01C2 0414 LSR – LSR – XON2/ADR2 XON2/ADDR2
0x01C2 0418 MSR/TCR
(3)
TCR
(3)
MSR/TCR
(3)
TCR
(3)
XOFF1/TCR
(3)
XOFF1/TCR
(3)
0x01C2 041C SPR/TLR
(3)
SPR/TLR
(3)
SPR/TLR
(3)
SPR/TLR
(3)
XOFF2/TLR
(3)
XOFF2/TLR
(3)
0x01C2 0420 MDR1 MDR1 MDR1 MDR1 MDR1 MDR1
0x01C2 0424 MDR2 MDR2 MDR2 MDR2 MDR2 MDR2
0x01C2 0428 SFLSR TXFLL SFLSR TXFLL SFLSR TXFLL
0x01C2 042C RESUME TXFLH RESUME TXFLH RESUME TXFLH
0x01C2 0430 SFREGL RXFLL SFREGL RXFLL SFREGL RXFLL
0x01C2 0434 SFREGH RXFLH SFREGH RXFLH SFREGH RXFLH
0x01C2 0438 BLR BLR UASR – UASR –
0x01C2 043C ACREG ACREG – – – –
0x01C2 0440 SCR SCR SCR SCR SCR SCR
0x01C2 0444 SSR – SSR – SSR –
0x01C2 0448 EBLR EBLR – – – –
0x01C2 044C – – – – – –
0x01C2 0450 MVR – MVR – MVR –
0x01C2 0454 SYSC SYSC SYSC SYSC SYSC SYSC
0x01C2 0458 SYSS – SYSS – SYSS –
0x01C2 045C WER WER WER WER WER WER
0x01C2 0460 CFPS CFPS CFPS CFPS CFPS CFPS
0x01C2 0464 - – – – – – –
0x01C2 047F
(1) In UART modes, IER.[7:4] can only be written when ENHANCED_EN in EFR = 1. In IrDA/CIR modes, ENHANCED_EN in EFR has no
impact on the access to IER.[7:4].
(2) MCR.[7:5] and the TX_FIFO_TRIG bits in FCR can only be written to when the ENHANCED_EN bit in EFR = 1.
(3) Transmission control register (TCR) and trigger level register (TLR) are accessible only when the ENHANCED_EN bit in the EFR =1
and the TCR_TLR bit in the MCR = 1.
Copyright © 2009–2012, Texas Instruments Incorporated Peripheral Information and Electrical Specifications 329
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
