Table 7-122. Additional Output Switching Characteristics of 5-Pin Option in Slave Mode
(1)
(continued)
-1G
NO. PARAMETER UNIT
MIN MAX
Delay time, final clock receive edge on SPI_CLK to slave
deasserting SPI_EN, polarity = 0, phase = 0, 3P + 15
SPIINT0.ENABLE HIGHZ = 0
Delay time, final clock receive edge on SPI_CLK to slave
0.5T + 3P +
deasserting SPI_EN, polarity = 0, phase = 1,
15
SPIINT0.ENABLE HIGHZ = 0
38 t
d(CLK-ENZ)
(2)
ns
Delay time, final clock receive edge on SPI_CLK to slave
deasserting SPI_EN, polarity = 1, phase = 0, 3P + 15
SPIINT0.ENABLE HIGHZ = 0
Delay time, final clock receive edge on SPI_CLK to slave
0.5T + 3P +
deasserting SPI_EN, polarity = 1, phase = 1,
15
SPIINT0.ENABLE HIGHZ = 0
Delay time, SPI_CS[n] deassertion to slave deasserting SPI_EN,
6
polarity = 0, phase = 0, SPIINT0.ENABLE HIGHZ = 0
Delay time, SPI_CS[n] deassertion to slave deasserting SPI_EN,
6
polarity = 0, phase = 1, SPIINT0.ENABLE HIGHZ = 0
39 t
d(CSH-ENH)
(2)
ns
Delay time, SPI_CS[n] deassertion to slave deasserting SPI_EN,
6
polarity = 1, phase = 0, SPIINT0.ENABLE HIGHZ = 0
Delay time, SPI_CS[n] deassertion to slave deasserting SPI_EN
6
polarity = 1, phase = 1, SPIINT0.ENABLE HIGHZ = 0
Table 7-123. Additional Input Timing Requirements of 5-Pin Option in Slave Mode
(1)
-1G
NO. UNIT
MIN MAX
Delay time, SPI_CS[n] asserted at slave to first clock edge (rising
35 t
d(CSL-CLK)
P ns
or falling) of SPI_CLK at slave
Delay time, SPI_CLK falling edge to SPI_CS[n] deasserted,
0.5T + P + 6
polarity = 0, phase = 0
Delay time, SPI_CLK falling edge to SPI_CS[n] deasserted,
P + 6
polarity = 0, phase = 1
36 t
d(CLK-CSH)
(2)
ns
Delay time, SPI_CLK rising edge to SPI_CS[n] deasserted, polarity
0.5T + P + 6
= 1, phase = 0
Delay time, SPI_CLK rising edge to SPI_CS[n] deasserted, polarity
P + 6
= 1, phase = 1
(1) T = period of SPI_CLK; P = period of SPI core clock
(2) Figure 7-87 shows only polarity = 0, phase = 0 as an example.
