Slave Mode — General
Table 7-112. General Switching Characteristics in Slave Mode (For 3-/4-/5-Pin Modes)
(1)
-1G
NO. PARAMETER UNIT
MIN MAX
Delay time, transmit rising edge of SPI_CLK to SPI_SOMI output
15
valid, 3-/4-/5-pin mode, polarity = 0, phase = 0
Delay time, transmit falling edge of SPI_CLK to SPI_SOMI output
15
valid, 3-/4-/5-pin mode, polarity = 0, phase = 1
13 t
d(CLK-SOMI)
ns
Delay time, transmit falling edge of SPI_CLK to SPI_SOMI output
15
valid, 3-/4-/5-pin mode, polarity = 1, phase = 0
Delay time, transmit rising edge of SPI_CLK to SPI_SOMI output
15
valid, 3-/4-/5-pin mode, polarity = 1, phase = 1
Output hold time, SPI_SOMI valid (except final bit) after receive
0.5T – 4
falling edge of SPI_CLK, 3-/4-/5-pin mode, polarity = 0, phase = 0
Output hold time, SPI_SOMI valid (except final bit) after receive
0.5T – 4
rising edge of SPI_CLK, 3-/4-/5-pin mode, polarity = 0, phase = 1
14 t
oh(CLK-SOMI)
ns
Output hold time, SPI_SOMI valid (except final bit) after receive
0.5T – 4
rising edge of SPI_CLK, 3-/4-/5-pin mode, polarity = 1, phase = 0
Output hold time, SPI_SOMI valid (except final bit) after receive
0.5T – 4
falling edge of SPI_CLK, 3-/4-/5-pin mode, polarity = 1, phase = 1
(1) T = period of SPI_CLK
