TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 7-111. General Input Timing Requirements in Master Mode
-1G
NO. UNIT
MIN MAX
Setup time, SPI_SOMI valid before receive falling edge of
SPI_CLK, 3-/4-/5-pin mode, 4
polarity = 0, phase = 0
Setup time, SPI_SOMI valid before receive rising edge of
SPI_CLK, 3-/4-/5-pin mode, 4
polarity = 0, phase = 1
7 t
su(SOMI-CLK)
ns
Setup time, SPI_SOMI valid before receive rising edge of
SPI_CLK, 3-/4-/5-pin mode, 4
polarity = 1, phase = 0
Setup time, SPI_SOMI valid before receive falling edge of
SPI_CLK, 3-/4-/5-pin mode, 4
polarity = 1, phase = 1
Hold time, SPI_SOMI valid after receive falling edge of SPI_CLK,
2
3-/4-/5-pin mode, polarity = 0, phase = 0
Hold time, SPI_SOMI valid after receive rising edge of SPI_CLK, 3-
2
/4-/5-pin mode, polarity = 0, phase = 1
8 t
h(CLK-SOMI)
ns
Hold time, SPI_SOMI valid after receive rising edge of SPI_CLK, 3-
2
/4-/5-pin mode, polarity = 1, phase = 0
Hold time, SPI_SOMI valid after receive falling edge of SPI_CLK,
2
3-/4-/5-pin mode, polarity = 1, phase = 1
