TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
7.23.3 SPI Electrical Data/Timing
Master Mode — General
Table 7-110. General Switching Characteristics in Master Mode
(1)
-1G
NO. PARAM2ETER UNIT
MIN MAX
1 t
c(CLK)
Cycle time, SPI_CLK 2P ns
2 t
w(CLKH)
Pulse width, SPI_CLK high P ns
3 t
w(CLKL)
Pulse width, SPI_CLK low P ns
Output setup time, SPI_SIMO valid (1st bit) before initial SPI_CLK
rising edge, 3-/4-/5-pin mode, 2P
polarity = 0, phase = 0
Output setup time, SPI_SIMO valid (1st bit) before initial SPI_CLK
rising edge, 3-/4-/5-pin mode, 0.5T + 2P
polarity = 0, phase = 1
4 t
osu(SIMO-CLK)
ns
Output setup time, SPI_SIMO valid (1st bit) before initial SPI_CLK
falling edge, 3-/4-/5-pin mode, 2P
polarity = 1, phase = 0
Output setup time, SPI_SIMO valid (1st bit) before initial SPI_CLK
falling edge, 3-/4-/5-pin mode, 0.5T + 2P
polarity = 1, phase = 1
Delay time, SPI_CLK transmit rising edge to SPI_SIMO output valid
5
(subsequent bit driven), 3-/4-/5-pin mode, polarity = 0, phase = 0
Delay time, SPI_CLK transmit falling edge to SPI_SIMO output
valid (subsequent bit driven), 3-/4-/5-pin mode, polarity = 0, phase 5
= 1
5 t
d(CLK-SIMO)
ns
Delay time, SPI_CLK transmit falling edge to SPI_SIMO output
valid (subsequent bit driven), 3-/4-/5-pin mode, polarity = 1, phase 5
= 0
Delay time, SPI_CLK transmit rising edge to SPI_SIMO output valid
5
(subsequent bit driven), 3-/4-/5-pin mode, polarity = 1, phase = 1
Output hold time, SPI_SIMO valid (except final bit) after receive
falling edge of SPI_CLK, 0.5T – 4
3-/4-/5-pin mode, polarity = 0, phase = 0
Output hold time, SPI_SIMO valid (except final bit) after receive
rising edge of SPI_CLK, 0.5T – 4
3-/4-/5-pin mode, polarity = 0, phase = 1
6 t
oh(CLK-SIMO)
ns
Output hold time, SPI_SIMO valid (except final bit) after receive
rising edge of SPI_CLK, 0.5T – 4
3-/4-/5-pin mode, polarity = 1, phase = 0
Output hold time, SPI_SIMO valid (except final bit) after receive
falling edge of SPI_CLK, 0.5T – 4
3-/4-/5-pin mode, polarity = 1, phase = 1
(1) T = period of SPI_CLK; P = period of SPI core clock
