TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
7.23 Serial Peripheral Interface (SPI)
The SPI is a high-speed synchronous serial input/output port that allows a serial bit stream of programmed
length (2-to-16 bits) to be shifted into and out of the device at a programmed bit-transfer rate. The SPI is
normally used for communication between the TMS320DM646x DMSoC and external peripherals. Typical
applications inlcude a interface to external I/O or peripheral expansion via devices such as shift regisers,
display drivers, SPI EEPROMs, and Analog-to-Digital Converters (ADCs).
7.23.1 SPI Device-Specific Information
The DM6467T SPI supports the following features:
• Master/slave operation
• 2 chip selects for interfacing/control to multiple SPI slave devices
• 3-, 4-, 5-wire interface [The DM6467T supports 3-pin mode, 2 4-pin modes, and the 5-pin mode.]
• 16-bit shift register
• Receive buffer register
• 8-bit clock prescaler
• Programmable SPI clock frequency range, character length, and clock phase and polarity
7.23.2 SPI Peripheral Register Description(s)
Table 7-109 shows the SPI registers.
Table 7-109. SPI Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME
01C6 6800 SPIGCR0 SPI Global Control Register 0
01C6 6804 SPIGCR1 SPI Global Control Register 1
01C6 5808 SPIINT SPI Interrupt Register
01C6 680C SPIILVL SPI Interrupt Level Register
01C6 6810 SPIFLG SPI Flag Status Register
01C6 6814 SPIPC0 SPI Pin Control Register 0
01C6 6818 – Reserved
01C6 681C SPIPC2 SPI Pin Control Register 2
01C6 6820 – 01C6 6838 – Reserved
01C6 683C SPIDAT1 SPI Shift Register 1
01C6 6840 SPIBUF SPI Buffer Register
01C6 6844 SPIEMU SPI Emulation Register
01C6 6848 SPIDELAY SPI Delay Register
01C6 684C SPIDEF SPI Default Chip Select Register
01C6 6850 SPIFMT0 SPI Data Format Register 0
01C6 6854 SPIFMT1 SPI Data Format Register 1
01C6 6858 SPIFMT2 SPI Data Format Register 2
01C6 685C SPIFMT3 SPI Data Format Register 3
01C6 6860 INTVEC0 SPI Interrupt Vector Register 0
01C6 6864 INTVEC1 SPI Interrupt Vector Register 1
01C6 6868 – 01C6 6FFF – Reserved
