TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 7-108. Switching Characteristics Over Recommended Operating Conditions for McASP1
(1) (2) (3)
(see Figure 7-82 and Figure 7-83)
-1G
NO. PARAMETER UNIT
MIN MAX
9 t
c(AHCKRX)
Cycle time, AHCLKX 41.7 ns
10 t
w(AHCKRX)
Pulse duration, AHCLKX high or low AH - 2.5 ns
11 t
c(CKRX)
Cycle time, ACLKX 41.7 ns
12 t
w(CKRX)
Pulse duration, ACLKX high or low ACLKR/X int A - 2.5 ns
ACLKX int -1 5 ns
14 t
d(CKX-AXRV)
Delay time, ACLKX transmit edge to AXR output valid
ACLKX ext 0 16 ns
ACLKX int -3 8 ns
Disable time, AXR high impedance following last data bit
15 t
dis(CKRX-AXRHZ)
from ACLKX transmit edge
ACLKX ext -3 15 ns
(1) A = (ACLKX period)/2 in ns. For example, when ACLKX period is 25 ns, use A = 12.5 ns.
(2) AH = (AHCLKX period)/2 in ns. For example, when AHCLKX period is 25 ns, use AH = 12.5 ns.
(3) ACLKX internal: ACLKXCTL.CLKXM=1, PDIR.ACLKX = 1
ACLKX external input: ACLKXCTL.CLKXM=0, PDIR.ACLKX=0
ACLKX external output: ACLKXCTL.CLKXM=0, PDIR.ACLKX=1
