TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 7-101. McASP0 Control Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
01D0 10D0 – 01D0 10FC – Reserved
01D0 1100 DITCSRA0 Left (even TDM slot) channel status register file
01D0 1104 DITCSRA1 Left (even TDM slot) channel status register file
01D0 1108 DITCSRA2 Left (even TDM slot) channel status register file
01D0 110C DITCSRA3 Left (even TDM slot) channel status register file
01D0 1110 DITCSRA4 Left (even TDM slot) channel status register file
01D0 1114 DITCSRA5 Left (even TDM slot) channel status register file
01D0 1118 DITCSRB0 Right (odd TDM slot) channel status register file
01D0 111C DITCSRB1 Right (odd TDM slot) channel status register file
01D0 1120 DITCSRB2 Right (odd TDM slot) channel status register file
01D0 1124 DITCSRB3 Right (odd TDM slot) channel status register file
01D0 1128 DITCSRB4 Right (odd TDM slot) channel status register file
01D0 112C DITCSRB5 Right (odd TDM slot) channel status register file
01D0 1130 DITUDRA0 Left (even TDM slot) user data register file
01D0 1134 DITUDRA1 Left (even TDM slot) user data register file
01D0 1138 DITUDRA2 Left (even TDM slot) user data register file
01D0 113C DITUDRA3 Left (even TDM slot) user data register file
01D0 1140 DITUDRA4 Left (even TDM slot) user data register file
01D0 1144 DITUDRA5 Left (even TDM slot) user data register file
01D0 1148 DITUDRB0 Right (odd TDM slot) user data register file
01D0 114C DITUDRB1 Right (odd TDM slot) user data register file
01D0 1150 DITUDRB2 Right (odd TDM slot) user data register file
01D0 1154 DITUDRB3 Right (odd TDM slot) user data register file
01D0 1158 DITUDRB4 Right (odd TDM slot) user data register file
01D0 115C DITUDRB5 Right (odd TDM slot) user data register file
01D0 1160 – 01D0 117C – Reserved
01D0 1180 SRCTL0 Serializer 0 control register
01D0 1184 SRCTL1 Serializer 1 control register
01D0 1188 SRCTL2 Serializer 2 control register
01D0 118C SRCTL3 Serializer 3 control register
01D0 1190 – 01D0 11FC – Reserved
01D0 1200 XBUF0 Transmit Buffer for Serializer 0
01D0 1204 XBUF1 Transmit Buffer for Serializer 1
01D0 1208 XBUF2 Transmit Buffer for Serializer 2
01D0 120C XBUF3 Transmit Buffer for Serializer 3
01D0 1210 – 01D0 127C – Reserved
01D0 1280 RBUF0 Receive Buffer for Serializer 0
01D0 1284 RBUF1 Receive Buffer for Serializer 1
01D0 1288 RBUF2 Receive Buffer for Serializer 2
01D0 128C RBUF3 Receive Buffer for Serializer 3
01D0 1290 – 01D0 13FF – Reserved
Copyright © 2009–2012, Texas Instruments Incorporated Peripheral Information and Electrical Specifications 301
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
