TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
3.7 Terminal Functions
The terminal functions tables (Table 3-5 through Table 3-32) identify the external signal names, the
associated pin (ball) numbers along with the mechanical package designator, the pin type, whether the pin
has any internal pullup or pulldown resistors, and a functional pin description. For more detailed
information on device configuration, peripheral selection, multiplexed/shared pin, and see the Device
Configurations section of this data manual.
30 Device Overview Copyright © 2009–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
