7.22 Multichannel Audio Serial Port (McASP0/1) Peripherals
The multichannel audio serial port (McASP) functions as a general-purpose audio serial port optimized for
the needs of multichannel audio applications. The McASP is useful for time-division multiplexed (TDM)
stream, Inter-Integrated Sound (I2S) protocols, and intercomponent digital audio interface transmission
(DIT).
7.22.1 McASP Device-Specific Information
The DM6467T device includes two multichannel audio serial port (McASP) interface peripherals (McASP0
and McASP1). The McASP0 module consists of a transmit and receive section. These sections can
operate completely independently with different data formats, separate master clocks, bit clocks, and
frame syncs or alternatively, the transmit and receive sections may be synchronized. The McASP0 module
also includes a pool of 4 shift registers that may be configured to operate as either transmit data or
receive data.
The transmit section of the McASP0 can transmit data in either a time-division-multiplexed (TDM)
synchronous serial format or in a digital audio interface (DIT) format where the bit stream is encoded for
S/PDIF, AES-3, IEC-60958, CP-430 transmission. The receive section of the McASP0 peripheral supports
the TDM synchronous serial format.
The McASP0 module can support one transmit data format (either a TDM format or DIT format) and one
receive format at a time. All transmit shift registers use the same format and all receive shift registers use
the same format. However, the transmit and receive formats need not be the same. Both the transmit and
receive sections of the McASP also support burst mode which is useful for non-audio data (for example,
passing control information between two DSPs).
The McASP0 peripheral has additional capability for flexible clock generation, and error
detection/handling, as well as error management.
The DM6467T McASP1 module is a reduced feature version of the McASP peripheral. The McASP1
module provides a single transmit-only shift register and can transmit data in DIT format only.
For more detailed information on and the functionality of the McASP peripheral, see the TMS320DM646x
DMSoC Multichannel Audio Serial Port (McASP) User's Guide (literature number SPRUER1).
