TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 7-94. VLYNQ Master Memory Map (continued)
SIZE
START ADDRESS END ADDRESS HPI ACCESS
(BYTES)
0x1002 0000 0x10FF FFFF 16256K
0x1100 0000 0x113F FFFF 4M
0x1140 0000 0x114F FFFF 1M
0x1150 0000 0x115F FFFF 1M
Reserved
0x1160 0000 0x116F FFFF 1M
0x1170 0000 0x117F FFFF 1M
0x1180 0000 0x1180 FFFF 64K
0x1181 0000 0x1181 7FFF 32K
0x1181 8000 0x1183 7FFF 128K C64x+ L2 RAM/Cache
0x1183 8000 0x118F FFFF 800K
Reserved
0x1190 0000 0x11DF FFFF 5M
0x11E0 0000 0x11E0 7FFF 32K C64x+ L1P RAM/Cache
0x11E0 8000 0x11EF FFFF 992K Reserved
0x11F0 0000 0x11F0 7FFF 32K C64x+ L1D RAM/Cache
0x11F0 8000 0x11FF FFFF 992K
Reserved
0x1200 0000 0x41FF FFFF 768M
0x4200 0000 0x43FF FFFF 32M EMIFA Data (CS2)
0x4400 0000 0x45FF FFFF 32M EMIFA Data (CS3)
0x4600 0000 0x47FF FFFF 32M EMIFA Data (CS4)
0x4800 0000 0x49FF FFFF 32M EMIFA Data (CS5)
0x4A00 0000 0x7FFF FFFF 864M Reserved
0x8000 0000 0x9FFF FFFF 512M DDR2 Memory Controller
0xA000 0000 0xBFFF FFFF 512M Reserved
0xC000 0000 0xFFFF FFFF 1G Reserved
7.21.2 VLYNQ Peripheral Register Description(s)
Table 7-95. VLYNQ Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0x2001 0000 REVID VLYNQ Revision Register
0x2001 0004 CTRL VLYNQ Local Control Register
0x2001 0008 STAT VLYNQ Local Status Register
0x2001 000C INTPRI VLYNQ Local Interrupt Priority Vector Status/Clear Register
0x2001 0010 INTSTATCLR VLYNQ Local Unmasked Interrupt Status/Clear Register
0x2001 0014 INTPENDSET VLYNQ Local Interrupt Pending/Set Register
0x2001 0018 INTPTR VLYNQ Local Interrupt Pointer Register
0x2001 001C XAM VLYNQ Local Transmit Address Map Register
0x2001 0020 RAMS1 VLYNQ Local Receive Address Map Size 1 Register
0x2001 0024 RAMO1 VLYNQ Local Receive Address Map Offset 1 Register
0x2001 0028 RAMS2 VLYNQ Local Receive Address Map Size 2 Register
0x2001 002C RAMO2 VLYNQ Local Receive Address Map Offset 2 Register
0x2001 0030 RAMS3 VLYNQ Local Receive Address Map Size 3 Register
0x2001 0034 RAMO3 VLYNQ Local Receive Address Map Offset 3 Register
0x2001 0038 RAMS4 VLYNQ Local Receive Address Map Size 4 Register
0x2001 003C RAMO4 VLYNQ Local Receive Address Map Offset 4 Register
0x2001 0040 CHIPVER VLYNQ Local Chip Version Register
Copyright © 2009–2012, Texas Instruments Incorporated Peripheral Information and Electrical Specifications 295
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
