DA[2:0],
ATA_CS0
,
ATA_CS1
HDDIR
DIOW
DD[15:0] (OUT)
t
C
(A)
t
C
(A)
A. t
C
≥ one cycle
DA[2:0],
ATA_CS0
,
ATA_CS1
t
C
(A)
HDDIR
DIOW
DD[15:0] (OUT)
t
C
(A)
A. t
C
≥ one cycle
TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
7.20.3.4 ATA HDDIR Timing
Figure 7-76 through Figure 7-79 show the behavior of HDDIR for the different types of transfers.
Table 7-93. Timing Requirements for HDDIR
(1)
-1G
NO. UNIT
MIN MAX
1 t
c
Cycle time, ATA_CS[1:0] to HDDIR low E - 3.1 ns
(1) E = ATA clock cycle
Figure 7-76. ATA HDDIR Taskfile Write/Single PIO Write Timing
Figure 7-77. ATA HDDIR PIO Postwrite Start Timing
