TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 7-86. USB2.0 Registers (continued)
HEX ADDRESS
ACRONYM REGISTER NAME
RANGE
Sets the operating speed, transaction protocol and peripheral endpoint number
0x01C6 453A HOST_TXTYPE
for the host TX endpoint.
Sets the polling interval for Interrupt/ISOC transactions or the NAK response
0x01C6 453B HOST_TXINTERVAL
timeout on Bulk transactions for host TX endpoint.
Sets the operating speed, transaction protocol and peripheral endpoint number
0x01C6 453C HOST_RXTYPE
for the host RX endpoint.
Sets the polling interval for Interrupt/ISOC transactions or the NAK response
0x01C6 453D HOST_RXINTERVAL
timeout on Bulk transactions for host RX endpoint.
Control and Status Register for Endpoint 4 - EOCSR4
0x01C6 4540 TXMAXP Maximum Packet Size for Peripheral/Host TX Endpoint
PERI_TXCSR Control Status Register for Peripheral TX Endpoint
0x01C6 4542
HOST_TXCSR Control Status Register for Host TX Endpoint
0x01C6 4544 RXMAXP Maximum Packet Size for Peripheral/Host RX Endpoint
PERI_RXCSR Control Status Register for Peripheral RX Endpoint
0x01C6 4546
HOST_RXCSR Control Status Register for Host RX Endpoint
0x01C6 4548 RXCOUNT Number of Bytes in Host RX Endpoint FIFO
Sets the operating speed, transaction protocol and peripheral endpoint number
0x01C6 454A HOST_TXTYPE
for the host TX endpoint.
Sets the polling interval for Interrupt/ISOC transactions or the NAK response
0x01C6 454B HOST_TXINTERVAL
timeout on Bulk transactions for host TX endpoint.
Sets the operating speed, transaction protocol and peripheral endpoint number
0x01C6 454C HOST_RXTYPE
for the host RX endpoint.
Sets the polling interval for Interrupt/ISOC transactions or the NAK response
0x01C6 454D HOST_RXINTERVAL
timeout on Bulk transactions for host RX endpoint.
Copyright © 2009–2012, Texas Instruments Incorporated Peripheral Information and Electrical Specifications 277
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
