TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012 www.ti.com
Table 7-86. USB2.0 Registers (continued)
HEX ADDRESS
ACRONYM REGISTER NAME
RANGE
Number of received bytes in Endpoint 0 FIFO. (Index register set to select
COUNT0
Endpoint 0)
0x01C6 4418
Number of bytes in host RX endpoint FIFO. (Index register set to select
RXCOUNT
Endpoints 1 - 4)
0x01C6 441A HOST_TYPE0 Defines the speed of Endpoint 0
Sets the operating speed, transaction protocol and peripheral endpoint number
0x01C6 441A HOST_TXTYPE
for the host TX endpoint. (Index register set to select Endpoints 1 - 4 only)
Sets the NAK response timeout on Endpoint 0. (Index register set to select
0x01C6 441B HOST_NAKLIMIT0
Endpoint 0)
Sets the polling interval for Interrupt/ISOC transactions or the NAK response
0x01C6 441B HOST_TXINTERVAL timeout on Bulk transactions for host TX endpoint. (Index register set to select
Endpoints 1 - 4 only)
Sets the operating speed, transaction protocol and peripheral endpoint number
0x01C6 441C HOST_RXTYPE
for the host RX endpoint. (Index register set to select Endpoints 1 - 4 only)
Sets the polling interval for Interrupt/ISOC transactions or the NAK response
0x01C6 441D HOST_RXINTERVAL timeout on Bulk transactions for host RX endpoint. (Index register set to select
Endpoints 1 - 4 only)
0x01C6 441F CONFIGDATA Returns details of core configuration (Index register set to select Endpoint 0)
0x01C6 4420 FIFO0 TX and RX FIFO Register for Endpoint 0
0x01C6 4424 FIFO1 TX and RX FIFO Register for Endpoint 1
0x01C6 4428 FIFO2 TX and RX FIFO Register for Endpoint 2
0x01C6 442C FIFO3 TX and RX FIFO Register for Endpoint 3
0x01C6 4430 FIFO4 TX and RX FIFO Register for Endpoint 4
0x01C6 4460 DEVCTL Device Control Register
0x01C6 4462 TXFIFOSZ TX Endpoint FIFO Size (Index register set to select Endpoints 0 - 4 only)
0x01C6 4463 RXFIFOSZ RX Endpoint FIFO Size (Index register set to select Endpoints 0 - 4 only)
0x01C6 4464 TXFIFOADDR TX Endpoint FIFO Address (Index register set to select Endpoints 0 - 4 only)
0x01C6 4466 RXFIFOADDR RX Endpoint FIFO Address (Index register set to select Endpoints 0 - 4 only)
Target Endpoint Control Registers (Valid Only in Host Mode) - EPTRG0
Address of the target function that has to be accessed through the associated TX
0x01C6 4480 TXFUNCADDR
Endpoint
Address of the hub that has to be accessed through the associated TX Endpoint.
0x01C6 4482 TXHUBADDR This is used only when full-speed or low-speed device is connected via a USB2.0
high-speed hub.
Port of the hub that has to be accessed through the associated TX Endpoint. This
0x01C6 4483 TXHUBPORT is used only when full-speed or low-speed device is connected via a USB2.0
high-speed hub.
Address of the target function that has to be accessed through the associated RX
0x01C6 4484 RXFUNCADDR
Endpoint
Address of the hub that has to be accessed through the associated RX Endpoint.
0x01C6 4486 RXHUBADDR This is used only when full-speed or low-speed device is connected via a USB2.0
high-speed hub.
Port of the hub that has to be accessed through the associated RX Endpoint.
0x01C6 4487 RXHUBPORT This is used only when full speed or low speed device is connected via a USB2.0
high speed hub
Target Endpoint Control Registers (Valid Only in Host Mode) - EPTRG1
Address of the target function that has to be accessed through the associated TX
0x01C6 4488 TXFUNCADDR
Endpoint
Address of the hub that has to be accessed through the associated TX Endpoint.
0x01C6 448A TXHUBADDR This is used only when full-speed or low-speed device is connected via a USB2.0
high-speed hub.
Port of the hub that has to be accessed through the associated TX Endpoint. This
0x01C6 448B TXHUBPORT is used only when full-speed or low-speed device is connected via a USB2.0
high-speed hub.
