TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 7-86. USB2.0 Registers (continued)
HEX ADDRESS
ACRONYM REGISTER NAME
RANGE
0x01C6 4104 TCPPIDMASTATEW1 TX CPPI DMA State Word 1
0x01C6 4108 TCPPIDMASTATEW2 TX CPPI DMA State Word 2
0x01C6 410C TCPPIDMASTATEW3 TX CPPI DMA State Word 3
0x01C6 4110 TCPPIDMASTATEW4 TX CPPI DMA State Word 4
0x01C6 4114 TCPPIDMASTATEW5 TX CPPI DMA State Word 5
0x01C6 4118 – Reserved
0x01C6 411C TCPPICOMPPTR TX CPPI Completion Pointer
0x01C6 4120 RCPPIDMASTATEW0 RX CPPI DMA State Word 0
0x01C6 4124 RCPPIDMASTATEW1 RX CPPI DMA State Word 1
0x01C6 4128 RCPPIDMASTATEW2 RX CPPI DMA State Word 2
0x01C6 412C RCPPIDMASTATEW3 RX CPPI DMA State Word 3
0x01C6 4130 RCPPIDMASTATEW4 RX CPPI DMA State Word 4
0x01C6 4134 RCPPIDMASTATEW5 RX CPPI DMA State Word 5
0x01C6 4138 RCPPIDMASTATEW6 RX CPPI DMA State Word 6
0x01C6 413C RCPPICOMPPTR RX CPPI Completion Pointer
TX/RX CCPI Channel 1 State Block
0x01C6 4140 TCPPIDMASTATEW0 TX CPPI DMA State Word 0
0x01C6 4144 TCPPIDMASTATEW1 TX CPPI DMA State Word 1
0x01C6 4148 TCPPIDMASTATEW2 TX CPPI DMA State Word 2
0x01C6 414C TCPPIDMASTATEW3 TX CPPI DMA State Word 3
0x01C6 4150 TCPPIDMASTATEW4 TX CPPI DMA State Word 4
0x01C6 4154 TCPPIDMASTATEW5 TX CPPI DMA State Word 5
0x01C6 4158 – Reserved
0x01C6 415C TCPPICOMPPTR TX CPPI Completion Pointer
0x01C6 4160 RCPPIDMASTATEW0 RX CPPI DMA State Word 0
0x01C6 4164 RCPPIDMASTATEW1 RX CPPI DMA State Word 1
0x01C6 4168 RCPPIDMASTATEW2 RX CPPI DMA State Word 2
0x01C6 416C RCPPIDMASTATEW3 RX CPPI DMA State Word 3
0x01C6 4170 RCPPIDMASTATEW4 RX CPPI DMA State Word 4
0x01C6 4174 RCPPIDMASTATEW5 RX CPPI DMA State Word 5
0x01C6 4178 RCPPIDMASTATEW6 RX CPPI DMA State Word 6
0x01C6 417C RCPPICOMPPTR RX CPPI Completion Pointer
TX/RX CCPI Channel 2 State Block
0x01C6 4180 TCPPIDMASTATEW0 TX CPPI DMA State Word 0
0x01C6 4184 TCPPIDMASTATEW1 TX CPPI DMA State Word 1
0x01C6 4188 TCPPIDMASTATEW2 TX CPPI DMA State Word 2
0x01C6 418C TCPPIDMASTATEW3 TX CPPI DMA State Word 3
0x01C6 4190 TCPPIDMASTATEW4 TX CPPI DMA State Word 4
0x01C6 4194 TCPPIDMASTATEW5 TX CPPI DMA State Word 5
0x01C6 4198 – Rserved
0x01C6 419C TCPPICOMPPTR TX CPPI Completion Pointer
0x01C6 41A0 RCPPIDMASTATEW0 RX CPPI DMA State Word 0
0x01C6 41A4 RCPPIDMASTATEW1 RX CPPI DMA State Word 1
0x01C6 41A8 RCPPIDMASTATEW2 RX CPPI DMA State Word 2
0x01C6 41AC RCPPIDMASTATEW3 RX CPPI DMA State Word 3
0x01C6 41B0 RCPPIDMASTATEW4 RX CPPI DMA State Word 4
0x01C6 41B4 RCPPIDMASTATEW5 RX CPPI DMA State Word 5
272 Peripheral Information and Electrical Specifications Copyright © 2009–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
