Table 7-85. USB2.0 DMA Master Memory Map (continued)
SIZE
START ADDRESS END ADDRESS USB2.0 DMA ACCESS
(BYTES)
0x8000 0000 0x9FFF FFFF 512M DDR2 Memory Controller
0xA000 0000 0xBFFF FFFF 512M Reserved
0xC000 0000 0xFFFF FFFF 1G Reserved
7.19.2 USB2.0 Device-Specific Information
The DM6467T USBCTL register (0x01C4 00034) is part of the System Module Registers. The USBCTL
register controls the USB data polarity, host/peripheral mode, and VBUS sense, along with the PHY power
and clock good, PHY PLL suspend override, and PHY power down. For more detailed information on the
USBCTL System Module Register, see Section 4.6.2, Peripheral Selection After Device Reset
For more detailed information on the USB2.0 peripheral, see the TMS320DM646x DMSoC Universal
Serial Bus (USB) Controller User's Guide (literature number SPRUER7).
270 Peripheral Information and Electrical Specifications Copyright © 2009–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
