7.18.4 HPI Electrical Data/Timing
Table 7-83. Timing Requirements for Host-Port Interface Cycles
(1) (2)
(see Figure 7-58 through Figure 7-
61)
-1G
NO. UNIT
MIN MAX
1 t
su(SELV-HSTBL)
Setup time, select signals
(3)
valid before HSTROBE low 5 ns
2 t
h(HSTBL-SELV)
Hold time, select signals
(3)
valid after HSTROBE low 2 ns
3 t
w(HSTBL)
Pulse duration, HSTROBE active low 15 ns
4 t
w(HSTBH)
Pulse duration, HSTROBE inactive high between consecutive accesses 2M ns
11 t
su(HDV-HSTBH)
Setup time, host data valid before HSTROBE high 5 ns
12 t
h(HSTBH-HDV)
Hold time, host data valid after HSTROBE high 0.15 ns
Hold time, HSTROBE low after HRDY low. HSTROBE should not be
13 t
h(HRDYL-HSTBL)
inactivated until HRDY is active (low); otherwise, HPI writes will not 0 ns
complete properly.
(1) HSTROBE refers to the following logical operation on HCS, HDS1, and HDS2: [NOT(HDS1 XOR HDS2)] OR HCS.
(2) M = SYSCLK3 period = (CPU clock frequency)/4 in ns. For example, when running parts at 1 GHz, use M = 4 ns.
(3) Select signals include: HCNTL[1:0], HR/W. For HPI16 mode only, select signals also includes HHWIL.
