Table 7-81. HPI Master Memory Map (continued)
SIZE
START ADDRESS END ADDRESS HPI ACCESS
(BYTES)
0x1002 0000 0x10FF FFFF 16256K
0x1100 0000 0x113F FFFF 4M
0x1140 0000 0x114F FFFF 1M
0x1150 0000 0x115F FFFF 1M
Reserved
0x1160 0000 0x116F FFFF 1M
0x1170 0000 0x117F FFFF 1M
0x1180 0000 0x1180 FFFF 64K
0x1181 0000 0x1181 7FFF 32K
0x1181 8000 0x1183 7FFF 128K C64x+ L2 RAM/Cache
0x1183 8000 0x118F FFFF 800K
Reserved
0x1190 0000 0x11DF FFFF 5M
0x11E0 0000 0x11E0 7FFF 32K C64x+ L1P RAM/Cache
0x11E0 8000 0x11EF FFFF 992K Reserved
0x11F0 0000 0x11F0 7FFF 32K C64x+ L1D RAM/Cache
0x11F0 8000 0x11FF FFFF 992K
Reserved
0x1200 0000 0x4BFF FFFF 928M
0x4C00 0000 0x4FFF FFFF 64M VLYNQ (Remote Data)
0x5000 0000 0x7FFF FFFF 768M Reserved
0x8000 0000 0x9FFF FFFF 512M DDR2 Memory Controller
0xA000 0000 0xBFFF FFFF 512M Reserved
0xC000 0000 0xFFFF FFFF 1G Reserved
7.18.3 HPI Peripheral Register Description(s)
Table 7-82. HPI Control Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME COMMENTS
01C6 7800 PID Peripheral Identification Register
The ARM/C64x+ has
01C6 7804 PWREMU_MGMT HPI power and emulation management register read/write access to the
PWREMU_MGMT register.
01C6 7808 - 01C6 782F - Reserved
The Host and the
ARM/C64x+ both have
01C6 7830 HPIC HPI control register
read/write access to the
HPIC register.
HPIA HPI address register The Host has read/write
01C6 7834
(HPIAW)
(1)
(Write) access to the HPIA registers.
The ARM/C64x+ has only
HPIA HPI address register
read access to the HPIA
01C6 7838
(HPIAR)
(1)
(Read)
registers.
01C6 783C - 01C6 7FFF - Reserved
(1) There are two 32-bit HPIA registers: HPIAR for read operations and HPIAW for write operations. The HPI can be configured such that
HPIAR and HPIAW act as a single 32-bit HPIA (single-HPIA mode) or as two separate 32-bit HPIAs (dual-HPIA mode) from the
perspective of the Host. The ARM/C64x+ can access HPIAW and HPIAR independently. For more details about the HPIA registers and
their modes, see the TMS320DM646x DMSoC Host Port Interface (HPI) User's Guide (literature number SPRUES1).
