TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
7.17 Management Data Input/Output (MDIO)
The Management Data Input/Output (MDIO) module continuously polls all 32 MDIO addresses in order to
enumerate all PHY devices in the system.
The Management Data Input/Output (MDIO) module implements the 802.3 serial management interface to
interrogate and control Ethernet PHY(s) using a shared two-wire bus. Host software uses the MDIO
module to configure the auto-negotiation parameters of each PHY attached to the EMAC, retrieve the
negotiation results, and configure required parameters in the EMAC module for correct operation. The
module is designed to allow almost transparent operation of the MDIO interface, with very little
maintenance from the core processor. Only one PHY may be connected at any given time.
For more detailed information on the MDIO peripheral, see the TMS320DM646x DMSoC Ethernet Media
Access Controller (EMAC)/Management Data Input/Output (MDIO) Module User's Guide (literature
number SPRUEQ6) . For a list of supported registers and register fields, see Table 7-78, MDIO Registers
in this data manual.
7.17.1 MDIO Peripheral Register Description(s)
Table 7-78. MDIO Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0x01C8 4000 VERSION MDIO version register
0x01C8 4004 CONTROL MDIO control register
0x01C8 4008 ALIVE MDIO PHY alive status register
0x01C8 400C LINK MDIO PHY link status register
0x01C8 4010 LINKINTRAW MDIO link status change interrupt (unmasked) register
0x01C8 4014 LINKINTMASKED MDIO link status change interrupt (masked) register
0x01C8 4018 - 0x01C8 401F – Reserved
0x01C8 4020 USERINTRAW MDIO user command complete interrupt (unmasked) register
0x01C8 4024 USERINTMASKED MDIO user command complete interrupt (masked) register
0x01C8 4028 USERINTMASKSET MDIO user command complete interrupt mask set register
0x01C8 402C USERINTMASKCLEAR MDIO user command complete interrupt mask clear register
0x01C8 4030 - 0x01C8 407F – Reserved
0x01C8 4080 USERACCESS0 MDIO user access register 0
0x01C8 4084 USERPHYSEL0 MDIO user PHY select register 0
0x01C8 4088 USERACCESS1 MDIO user access register 1
0x01C8 408C USERPHYSEL1 MDIO user PHY select register 1
0x01C8 4090 - 0x01C8 47FF – Reserved
