TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 7-68. EMAC Statistics Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0x01C8 0244 TXDEFERRED Deferred transmit frames register
0x01C8 0248 TXCOLLISION Transmit collision frames register
0x01C8 024C TXSINGLECOLL Transmit single collision frames register
0x01C8 0250 TXMULTICOLL Transmit multiple collision frames register
0x01C8 0254 TXEXCESSIVECOLL Transmit excessive collision frames register
0x01C8 0258 TXLATECOLL Transmit late collision frames register
0x01C8 025C TXUNDERRUN Transmit underrun error register
0x01C8 0260 TXCARRIERSENSE Transmit carrier sense errors register
0x01C8 0264 TXOCTETS Transmit octet frames register
0x01C8 0268 FRAME64 Transmit and receive 64 octet frames register
0x01C8 026C FRAME65T127 Transmit and receive 65 to 127 octet frames register
0x01C8 0270 FRAME128T255 Transmit and receive 128 to 255 octet frames register
0x01C8 0274 FRAME256T511 Transmit and receive 256 to 511 octet frames register
0x01C8 0278 FRAME512T1023 Transmit and receive 512 to 1023 octet frames register
0x01C8 027C FRAME1024TUP Transmit and receive 1024 to 1518 octet frames register
0x01C8 0280 NETOCTETS Network octet frames register
0x01C8 0284 RXSOFOVERRUNS Receive FIFO or DMA start of frame overruns register
0x01C8 0288 RXMOFOVERRUNS Receive FIFO or DMA middle of frame overruns register
0x01C8 028C RXDMAOVERRUNS Receive DMA start of frame and middle of frame overruns register
0x01C8 0290 - 0x01C8 02FF – Reserved
Table 7-69. EMAC Control Module Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0x01C8 1000 CMIDVER Identification and version register
0x01C8 1004 CMSOFTRESET Software reset register
0x01C8 1008 CMEMCONTROL Emulation control register
0x01C8 100C CMINTCTRL Interrupt control register
0x01C8 1010 CMRXTHRESHINTEN Receive threshold interrupt enable register
0x01C8 1014 CMRXINTEN Receive interrupt enable register
0x01C8 1018 CMTXINTEN Transmit interrupt enable register
0x01C8 101C CMMISCINTEN Miscellaneous interrupt enable register
0x01C8 1020 - 0x01C8 103F – Reserved
0x01C8 1040 CMRXTHRESHINTSTAT Receive threshold interrupt status register
0x01C8 1044 CMRXINTSTAT Receive interrupt status register
0x01C8 1048 CMTXINTSTAT Transmit interrupt status register
0x01C8 104C CMMISCINTSTAT Miscellaneous interrupt status register
0x01C8 1050 - 0x01C8 106F – Reserved
0x01C8 1070 CMRXINTMAX Receive interrupts per millisecond register
0x01C8 1074 CMTXINTMAX Transmit interrupts per millisecond register
0x01C8 1078 - 0x01C8 10FF – Reserved
0x01C8 1100 - 0x01C8 1FFF – Reserved
Table 7-70. EMAC Descriptor Memory
HEX ADDRESS RANGE ACRONYM DESCRIPTION
0x01C8 2000 - 0x01C8 3FFF – EMAC Control Module Descriptor Memory
