TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 7-67. Ethernet MAC (EMAC) Control Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
Transmit channel 4 completion pointer (interrupt acknowledge)
0x01C8 0650 TX4CP
register
Transmit channel 5 completion pointer (interrupt acknowledge)
0x01C8 0654 TX5CP
register
Transmit channel 6 completion pointer (interrupt acknowledge)
0x01C8 0658 TX6CP
register
Transmit channel 7 completion pointer (interrupt acknowledge)
0x01C8 065C TX7CP
register
Receive channel 0 completion pointer (interrupt acknowledge)
0x01C8 0660 RX0CP
register
Receive channel 1 completion pointer (interrupt acknowledge)
0x01C8 0664 RX1CP
register
Receive channel 2 completion pointer (interrupt acknowledge)
0x01C8 0668 RX2CP
register
Receive channel 3 completion pointer (interrupt acknowledge)
0x01C8 066C RX3CP
register
Receive channel 4 completion pointer (interrupt acknowledge)
0x01C8 0670 RX4CP
register
Receive channel 5 completion pointer (interrupt acknowledge)
0x01C8 0674 RX5CP
register
Receive channel 6 completion pointer (interrupt acknowledge)
0x01C8 0678 RX6CP
register
Receive channel 7 completion pointer (interrupt acknowledge)
0x01C8 067C RX7CP
register
0x01C8 0680 - 0x01C8 07FF – Reserved
Table 7-68. EMAC Statistics Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0x01C8 0200 RXGOODFRAMES Good receive frames register
Broadcast receive frames register
0x01C8 0204 RXBCASTFRAMES
(Total number of good broadcast frames received)
Multicast receive frames register
0x01C8 0208 RXMCASTFRAMES
(Total number of good multicast frames received)
0x01C8 020C RXPAUSEFRAMES Pause receive frames register
Receive CRC errors register
0x01C8 0210 RXCRCERRORS
(Total number of frames received with CRC errors)
Receive alignment/code errors register
0x01C8 0214 RXALIGNCODEERRORS
(Total number of frames received with alignment/code errors)
Receive oversized frames register
0x01C8 0218 RXOVERSIZED
(Total number of oversized frames received)
Receive jabber frames register
0x01C8 021C RXJABBER
(Total number of jabber frames received)
Receive undersized frames register
0x01C8 0220 RXUNDERSIZED
(Total number of undersized frames received)
0x01C8 0224 RXFRAGMENTS Receive Frame Fragments Register
0x01C8 0228 RXFILTERED Filtered receive frames register
0x01C8 022C RXQOSFILTERED Received QOS filtered frames register
Receive octet frames register
0x01C8 0230 RXOCTETS
(Total number of received bytes in good frames)
Good Transmit Frames Register
0x01C8 0234 TXGOODFRAMES
(Total number of good frames transmitted)
0x01C8 0238 TXBCASTFRAMES Broadcast transmit frames register
0x01C8 023C TXMCASTFRAMES Multicast transmit frames register
0x01C8 0240 TXPAUSEFRAMES Pause transmit frames register
Copyright © 2009–2012, Texas Instruments Incorporated Peripheral Information and Electrical Specifications 253
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
