TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 7-67. Ethernet MAC (EMAC) Control Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0x01C8 0158 RX6FREEBUFFER Receive channel 6 free buffer count register
0x01C8 015C RX7FREEBUFFER Receive channel 7 free buffer count register
0x01C8 0160 MACCONTROL MAC control register
0x01C8 0164 MACSTATUS MAC status register
0x01C8 0168 EMCONTROL Emulation control register
0x01C8 016C FIFOCONTROL FIFO control register (transmit and receive)
0x01C8 0170 MACCONFIG MAC configuration register
0x01C8 0174 SOFTRESET Soft reset register
0x01C8 0178 - 0x01C8 01CF – Reserved
0x01C8 01D0 MACSRCADDRLO MAC source address low bytes register (lower 16-bits)
0x01C8 01D4 MACSRCADDRHI MAC source address high bytes register (upper 32-bits)
0x01C8 01D8 MACHASH1 MAC hash address register 1
0x01C8 01DC MACHASH2 MAC hash address register 2
0x01C8 01E0 BOFFTEST Back off test register
0x01C8 01E4 TPACETEST Transmit pacing algorithm test register
0x01C8 01E8 RXPAUSE Receive pause timer register
0x01C8 01EC TXPAUSE Transmit pause timer register
0x01C8 01F0 - 0x01C8 01FF – Reserved
0x01C8 0200 - 0x01C8 02FF (see Table 7-68) EMAC statistics registers
0x01C8 0300 - 0x01C8 04FF – Reserved
0x01C8 0500 MACADDRLO MAC address low bytes register (used in receive address matching)
0x01C8 0504 MACADDRHI MAC address high bytes register (used in receive address matching)
0x01C8 0508 MACINDEX MAC index register
0x01C8 050C - 0x01C8 05FF – Reserved
0x01C8 0600 TX0HDP Transmit channel 0 DMA head descriptor pointer register
0x01C8 0604 TX1HDP Transmit channel 1 DMA head descriptor pointer register
0x01C8 0608 TX2HDP Transmit channel 2 DMA head descriptor pointer register
0x01C8 060C TX3HDP Transmit channel 3 DMA head descriptor pointer register
0x01C8 0610 TX4HDP Transmit channel 4 DMA head descriptor pointer register
0x01C8 0614 TX5HDP Transmit channel 5 DMA head descriptor pointer register
0x01C8 0618 TX6HDP Transmit channel 6 DMA head descriptor pointer register
0x01C8 061C TX7HDP Transmit channel 7 DMA head descriptor pointer register
0x01C8 0620 RX0HDP Receive channel 0 DMA head descriptor pointer register
0x01C8 0624 RX1HDP Receive channel 1 DMA head descriptor pointer register
0x01C8 0628 RX2HDP Receive channel 2 DMA head descriptor pointer register
0x01C8 062C RX3HDP Receive channel 3 DMA head descriptor pointer register
0x01C8 0630 RX4HDP Receive channel 4 DMA head descriptor pointer register
0x01C8 0634 RX5HDP Receive channel 5 DMA head descriptor pointer register
0x01C8 0638 RX6HDP Receive channel 6 DMA head descriptor pointer register
0x01C8 063C RX7HDP Receive channel 7 DMA head descriptor pointer register
Transmit channel 0 completion pointer (interrupt acknowledge)
0x01C8 0640 TX0CP
register
Transmit channel 1 completion pointer (interrupt acknowledge)
0x01C8 0644 TX1CP
register
Transmit channel 2 completion pointer (interrupt acknowledge)
0x01C8 0648 TX2CP
register
Transmit channel 3 completion pointer (interrupt acknowledge)
0x01C8 064C TX3CP
register
