7.16.2 EMAC Bus Master Memory Map
The EMAC control module includes a multi-channel DMA engine which is used to transfer receive and
transmit packets between the EMAC and DM6467T memory. Table 7-66 shows the memory map for the
EMAC DMA.
Table 7-66. EMAC DMA Master Memory Map
SIZE
START ADDRESS END ADDRESS EMAC DMA ACCESS
(BYTES)
0x0000 0000 0x3FFF FFFF 1G Reserved
0x4000 0000 0x4BFF FFFF 192M Reserved
0x4C00 0000 0x4FFF FFFF 64M VLYNQ (Remote Data)
0x5000 0000 0x7FFF FFFF 768M Reserved
0x8000 0000 0x9FFF FFFF 512M DDR2 Memory Controller
0xA000 0000 0xBFFF FFFF 512M Reserved
0xC000 0000 0xFFFF FFFF 1G Reserved
