TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
7.15.3 PCI Peripheral Register Description(s)
Table 7-62. PCI Back End Configuration Registers
DMSoC ACCESS
ACRONYM DMSoC ACCESS REGISTER NAME
HEX ADDRESS RANGE
01C1 A000 - 01C1 A00F - Reserved
01C1 A010 PCISTATSET PCI Status Set Register
01C1 A014 PCISTATCLR PCI Status Clear Register
01C1 A018 - 01C1 A01F - Reserved
01C1 A020 PCIHINTSET PCI Host Interrupt Enable Set Register
01C1 A024 PCIHINTCLR PCI Host Interrupt Enable Clear Register
01C1 A028 - 01C1 A02F - Reserved
01C1 A030 PCIBINTSET PCI Back End Application Interrupt Enable Set Register
01C1 A034 PCIBINTCLR PCI Back End Application Interrupt Enable Clear Register
01C1 A038 - Reserved
01C1 A03C - 01C1 A0FF - Reserved
01C1 A100 PCIVENDEVMIR PCI Vendor ID/Device ID Mirror Register
01C1 A104 PCICSRMIR PCI Command/Status Mirror Register
01C1 A108 PCICLREVMIR PCI Class Code/Revision ID Mirror Register
01C1 A10C PCICLINEMIR PCI BIST/Header Type/Latency Timer/Cacheline Size Mirror Register
01C1 A110 PCIBAR0MSK PCI Base Address Mask Register 0
01C1 A114 PCIBAR1MSK PCI Base Address Mask Register 1
01C1 A118 PCIBAR2MSK PCI Base Address Mask Register 2
01C1 A11C PCIBAR3MSK PCI Base Address Mask Register 3
01C1 A120 PCIBAR4MSK PCI Base Address Mask Register 4
01C1 A124 PCIBAR5MSK PCI Base Address Mask Register 5
01C1 A128 - 01C1 A12B - Reserved
01C1 A12C PCISUBIDMIR PCI Subsystem Vendor ID/Subsystem ID Mirror Register
01C1 A130 - Reserved
01C1 A134 PCICPBPTRMIR PCI Capabilities Pointer Mirror Register
01C1 A138 - 01C1 A13B - Reserved
01C1 A13C PCILGINTMIR PCI Max Latency/Min Grant/Interrupt Pin/Interrupt Line Mirror Register
01C1 A140 - 01C1 A17F - Reserved
01C1 A180 PCISLVCNTL PCI Slave Control Register
01C1 A184 - 01C1 A1BF - Reserved
01C1 A1C0 PCIBAR0TRL PCI Slave Base Address 0 Translation Register
01C1 A1C4 PCIBAR1TRL PCI Slave Base Address 1 Translation Register
01C1 A1C8 PCIBAR2TRL PCI Slave Base Address 2 Translation Register
01C1 A1CC PCIBAR3TRL PCI Slave Base Address 3 Translation Register
01C1 A1D0 PCIBAR4TRL PCI Slave Base Address 4 Translation Register
01C1 A1D4 PCIBAR5TRL PCI Slave Base Address 5 Translation Register
01C1 A1D8 - 01C1 A1DF - Reserved
01C1 A1E0 PCIBAR0MIR PCI Base Address Register 0 Mirror Register
01C1 A1E4 PCIBAR1MIR PCI Base Address Register 1 Mirror Register
01C1 A1E8 PCIBAR2MIR PCI Base Address Register 2 Mirror Register
01C1 A1EC PCIBAR3MIR PCI Base Address Register 3 Mirror Register
01C1 A1F0 PCIBAR4MIR PCI Base Address Register 4 Mirror Register
01C1 A1F4 PCIBAR5MIR PCI Base Address Register 5 Mirror Register
01C1 A1F8 - 01C1 A2FF - Reserved
01C1 A300 PCIMCFGDAT PCI Master Configuration/IO Access Data Register
