TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
7.15.2 PCI External Master Memory Map
The PCI port includes a local DMA interface that allows external PCI master device intiated transfers to
access the DM646x system bus. Table 7-61 shows the memory map for the PCI interface.
Table 7-61. PCI DMA Master Memory Map
SIZE
START ADDRESS END ADDRESS PCI DMA ACCESS
(BYTES)
0x0000 0000 0x01BF FFFF 28M Reserved
0x01C0 0000 0x0FFF FFFF 228M CFG Bus Peripherals
0x1001 0000 0x1001 3FFF 16K ARM RAM 0 (Data)
0x1001 4000 0x1001 7FFF 16K ARM RAM 1 (Data)
0x1001 8000 0x1001 FFFF 32K ARM ROM (Data)
0x1002 0000 0x10FF FFFF 16256K
0x1100 0000 0x113F FFFF 4M
0x1140 0000 0x114F FFFF 1M
0x1150 0000 0x115F FFFF 1M
Reserved
0x1160 0000 0x116F FFFF 1M
0x1170 0000 0x117F FFFF 1M
0x1180 0000 0x1180 FFFF 64K
0x1181 0000 0x1181 7FFF 32K
0x1181 8000 0x1183 7FFF 128K C64x+ L2 RAM/Cache
0x1183 8000 0x118F FFFF 800K
Reserved
0x1190 0000 0x11DF FFFF 5M
0x11E0 0000 0x11E0 7FFF 32K C64x+ L1P RAM/Cache
0x11E0 8000 0x11EF FFFF 992K Reserved
0x11F0 0000 0x11F0 7FFF 32K C64x+ L1D RAM/Cache
0x11F0 8000 0x11FF FFFF 992K
Reserved
0x1200 0000 0x4BFF FFFF 928M
0x4C00 0000 0x4FFF FFFF 64M VLYNQ (Remote Data)
0x5000 0000 0x7FFF FFFF 768M Reserved
0x8000 0000 0x9FFF FFFF 512M DDR2 Memory Controller
0xA000 0000 0xBFFF FFFF 512M Reserved
0xC000 0000 0xFFFF FFFF 1G Reserved
