TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
7.14.2 VDCE Register Description(s)
Table 7-59 shows the VDCE registers.
Table 7-59. VDCE Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0x01C1 2800 PID VDCE peripheral identification register
0x01C1 2804 CTRL VDCE control register
0x01C1 2808 INTEN Interrupt enable register
0x01C1 280C INTEN_SET Interrupt enable set register
0x01C1 2810 INTEN_CLR Interrupt enable clear register
0x01C1 2814 INTSTAT Interrupt status register
0x01C1 2818 INTSTAT_CLR Interrupt status clear register
0x01C1 281C EMU_CTRL Emulation control register
0x01C1 2820 SRD_FRMT Source/Result data store format register
0x01C1 2824 REQ_SIZE Request unit size register
0x01C1 2828 PROC_SIZE Processing unit size register
0x01C1 282C - 0x01C1 283F – Reserved
0x01C1 2840 TY_SRCADDR Luma top field source start address register
0x01C1 2844 TY_SRCSPSIZE Luma top field source sub-picture size register
0x01C1 2848 TY_SRCOFFSET Luma top field line source address offset size register
0x01C1 284C BY_SRCADDR Luma bottom field source start address register
0x01C1 2850 BY_SRCSPSIZE Luma bottom field source sub-picture size register
0x01C1 2854 BY_SRCOFFSET Luma bottom field line source address offset size register
0x01C1 2858 TC_SRCADDR Chroma top field source start address register
0x01C1 285C TC_SRCSPSIZE Chroma top field source sub-picture size register
0x01C1 2860 TC_SRCOFFSET Chroma top field line source address offset size register
0x01C1 2864 BC_SRCADDR Chroma bottom field source start address register
0x01C1 2868 BC_SRCSPSIZE Chroma bottom field source sub-picture size register
0x01C1 286C BC_SRCOFFSET Chroma bottom field line source address offset size register
0x01C1 2870 TBMP_SRCADDR Bitmap top field source start address register
0x01C1 2874 TBMP_SRCOFFSET Bitmap top field line source address offset register
0x01C1 2878 BBMP_SRCADDR Bitmap bottom field source start address register
0x01C1 287C BBMP_SRCOFFSET Bitmap bottom field line source address offset register
0x01C1 2880 TY_RESADDR Luma top field result start address register
0x01C1 2884 TY_RESSPSIZE Luma top field result sub-picture size register
0x01C1 2888 TY_RESOFFSET Luma top field line result address offset size register
0x01C1 288C BY_RESADDR Luma bottom field result start address register
0x01C1 2890 BY_RESSPSIZE Luma bottom field result sub-picture size register
0x01C1 2894 BY_RESOFFSET Luma bottom field line result address offset size register
0x01C1 2898 TC_RESADDR Chroma top field result start address register
0x01C1 289C TC_RESSPSIZE Chroma top field result sub-picture size register
0x01C1 28A0 TC_RESOFFSET Chroma top field result line address offset size register
0x01C1 28A4 BC_RESADDR Chroma bottom field result start address register
0x01C1 28A8 BC_RESSPSIZE Chroma bottom field result sub-picture size register
0x01C1 28AC BC_RESOFFSET Chroma bottom field line result address offset size register
0x01C1 28B0 - 0x01C1 28BF – Reserved
0x01C1 28C0 IMG_Y_SRCSTRTPOS Luminance source image start position register
0x01C1 28C4 IMG_Y_SRCSIZE Luminance source image size register
0x01C1 28C8 IMG_C_SRCSTRTPOS Chrominance source image start position register
