TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
7.13 Clock Recovery Generator (CRGEN)
Each TSIF module has an associated CRGEN module which can adjust the local system time clock based
upon the received Program Clock Reference (PCR) packets. CRGEN0 may only be used with TSIF 0 and
CRGEN 1 may only be used with TSIF 1.
Each CRGEN module features:
• Automatic load of received PCR packet values from associated TSIF module
• Local System Time Clock (STC) counter
• PCR/STC difference generator (subtractor)
• Loop Filter (LPF)
• 1-bit sigma/delta modulator digital-to-analog converter (DAC) output for external VCXO control
7.13.1 CRGEN Peripheral Register Description(s)
The CRGEN0 and CRGEN1 registers are shown in Table 7-54 and Table 7-55, respectively.
Table 7-54. CRGEN0 Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0x01C2 6000 PID CRGEN Peripheral Identification Register
0x01C2 6004 CONTROL CRGEN control register
0x01C2 6008 STC_HI System Time Clock (STC) current value (upper 17 bits)
0x01C2 600C STC_LO STC current value (lower 16 bits plus extension)
0x01C2 6010 STC_VAL_HI STC value (upper 17 bits) on TSIF0 PCR packet detection
STC value (lower 16 bits plus extension) on TSIF0 PCR packet
0x01C2 6014 STC_VAL_LO
detection
Program Clock Reference (PCR) value (upper 17 bits) from
0x01C2 6018 PCR_HI
TSIF0 Receive packet
PCR value (lower 16 bits plus extension) from TSIF0 Receive
0x01C2 601C PCR_LO
packet
0x01C2 6020 PCR_PKT_STAT PCR packet status
0x01C2 6024 LOOP_FILTER Loop filter (LPF) interface
Offset value of the STC counter for the higher (upper) 17 bits.
0x01C2 6028 STC_OFFSET_HI This value is detected in the STC counter with the first PCR
loading pulse signal.
Offset value of the STC counter for the lower 16 bits. The role
0x01C2 602C STC_OFFSET_LO
of this register is same as the STC_LO register 0x01C2 600C.
0x01C2 6030 - 0x01C2 603F - Reserved
0x01C2 6040 INTEN Interrupt enable
0x01C2 6044 INTEN_SET Interrupt enable set
0x01C2 6048 INTEN_CLR Interrupt enable clear
0x01C2 604C INTSTAT Interrupt status
0x01C2 6050 INTSTAT_CLR Interrupt status clear
0x01C2 6054 EMU_CTRL Emulation control
0x01C2 6058 - 0x01C2 607F - Reserved
