9
TSx_CLKO
(PositiveEdgeClocking)
TSx_CTL/
TSx_DATA
(A)
TSx_CLKO
(NegativeEdgeClocking)
9
7
7
6
8
8
TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 7-53. Switching Characteristics Over Recommended Operating Conditions for TSIF Output
(see Figure 7-46) (continued)
-1G
SERIAL PARALLEL
NO. UNIT
OUTPUT OUTPUT
(1)
MIN MAX MIN MAX
All Others 1 7.5 1 7.5 ns
Delay time, TSx_CLKO edge to
9 t
d(TSCLKOV-TSDATAO)
TS0_WAITO,
TSx_CTL/TSx_DATA
(4)
output valid
1 16.5 1 16.5 ns
TSx_EN_WAITO
(4) TSx_CTL/TSx_DATA output includes: TS0_ENAO, TS0_WAITO, TS0_PSTO, and TS0_DOUT[7:0] for a parallel output. For a serial
output, TSx_CTL/TSx_DATA output includes: TSx_ENAO, TSx_EN_WAITO, TSx_PSTO, and TS0_DOUT7 or TS1_DOUT.
A. TSx_CTL/TSx_DATA output includes: TS0_ENAO, TS0_WAITO, TS0_PSTO, and TS0_DOUT[7:0] for a parallel
output. For a serial output, TSx_CTL/TSx_DATA output includes: TSx_ENAO, TSx_EN_WAITO, TSx_PSTO, and
TS0_DOUT7 or TS1_DOUT.
Figure 7-46. TSIF Output Timing
