TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 7-51. TSIF1 Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0x01C1 3528 WRB3_RDPTR Write ring buffer channel 3 read pointer register
0x01C1 352C WRB3_SUB Write ring buffer channel 3 subtraction register
0x01C1 3530 WRB3_WRPTR Write ring buffer channel 3 write pointer register
0x01C1 3534 - 0x01C1 353F – Reserved
0x01C1 3540 WRB4_STRT_ADDR Write ring buffer channel 4 start address register
0x01C1 3544 WRB4_END_ADDR Write ring buffer channel 4 end address register
0x01C1 3548 WRB4_RDPTR Write ring buffer channel 4 read pointer register
0x01C1 354C WRB4_SUB Write ring buffer channel 4 subtraction register
0x01C1 3550 WRB4_WRPTR Write ring buffer channel 4 write pointer register
0x01C1 3554 - 0x01C1 355F – Reserved
0x01C1 3560 WRB5_STRT_ADDR Write ring buffer channel 5 start address register
0x01C1 3564 WRB5_END_ADDR Write ring buffer channel 5 end address register
0x01C1 3568 WRB5_RDPTR Write ring buffer channel 5 read pointer register
0x01C1 356C WRB5_SUB Write ring buffer channel 5 subtraction register
0x01C1 3570 WRB5_WRPTR Write ring buffer channel 5 write pointer register
0x01C1 3574 - 0x01C1 357F – Reserved
0x01C1 3580 WRB6_STRT_ADDR Write ring buffer channel 6 start address register
0x01C1 3584 WRB6_END_ADDR Write ring buffer channel 6 end address register
0x01C1 3588 WRB6_RDPTR Write ring buffer channel 6 read pointer register
0x01C1 358C WRB6_SUB Write ring buffer channel 6 subtraction register
0x01C1 3590 WRB6_WRPTR Write ring buffer channel 6 write pointer register
0x01C1 3594 - 0x01C1 359F – Reserved
0x01C1 35A0 WRB7_STRT_ADDR Write ring buffer channel 7 start address register
0x01C1 35A4 WRB7_END_ADDR Write ring buffer channel 7 end address register
0x01C1 35A8 WRB7_RDPTR Write ring buffer channel 7 read pointer register
0x01C1 35AC WRB7_SUB Write ring buffer channel 7 subtraction register
0x01C1 35B0 WRB7_WRPTR Write ring buffer channel 7 write pointer register
0x01C1 35B4 - 0x01C1 35BF – Reserved
0x01C1 35C0 RRB_CTRL Read ring buffer channel control register
0x01C1 35C4 RRB_STRT_ADDR Read ring buffer channel start address register
0x01C1 35C8 RRB_END_ADDR Read ring buffer channel end address register
0x01C1 35CC RRB_WRPTR Read ring buffer channel write pointer register
0x01C1 35D0 RRB_SUB Read ring buffer channel subtraction register
0x01C1 35D4 RRB_RDPTR Read ring buffer channel read pointer register
0x01C1 35D8 PKT_CNT Packet counter value register
0x01C1 35DC - 0x01C1 35FF – Reserved
