TMS320DM6467T

SPRS605C –JULY 2009–REVISED JUNE 2012

www.ti.com

Table 7-50. TSIF0 Registers (continued)

HEX ADDRESS RANGE ACRONYM REGISTER NAME

0x01C1 314C WRB4_SUB Write ring buffer channel 4 subtraction register

0x01C1 3150 WRB4_WRPTR Write ring buffer channel 4 write pointer register

0x01C1 3154 - 0x01C1 315F – Reserved

0x01C1 3160 WRB5_STRT_ADDR Write ring buffer channel 5 start address register

0x01C1 3164 WRB5_END_ADDR Write ring buffer channel 5 end address register

0x01C1 3168 WRB5_RDPTR Write ring buffer channel 5 read pointer register

0x01C1 316C WRB5_SUB Write ring buffer channel 5 subtraction register

0x01C1 3170 WRB5_WRPTR Write ring buffer channel 5 write pointer register

0x01C1 3174 - 0x01C1 317F – Reserved

0x01C1 3180 WRB6_STRT_ADDR Write ring buffer channel 6 start address register

0x01C1 3184 WRB6_END_ADDR Write ring buffer channel 6 end address register

0x01C1 3188 WRB6_RDPTR Write ring buffer channel 6 read pointer register

0x01C1 318C WRB6_SUB Write ring buffer channel 6 subtraction register

0x01C1 3190 WRB6_WRPTR Write ring buffer channel 6 write pointer register

0x01C1 3194 - 0x01C1 319F – Reserved

0x01C1 31A0 WRB7_STRT_ADDR Write ring buffer channel 7 start address register

0x01C1 31A4 WRB7_END_ADDR Write ring buffer channel 7 end address register

0x01C1 31A8 WRB7_RDPTR Write ring buffer channel 7 read pointer register

0x01C1 31AC WRB7_SUB Write ring buffer channel 7 subtraction register

0x01C1 31B0 WRB7_WRPTR Write ring buffer channel 7 write pointer register

0x01C1 31B4 - 0x01C1 31BF – Reserved

0x01C1 31C0 RRB_CTRL Read ring buffer channel control register

0x01C1 31C4 RRB_STRT_ADDR Read ring buffer channel start address register

0x01C1 31C8 RRB_END_ADDR Read ring buffer channel end address register

0x01C1 31CC RRB_WRPTR Read ring buffer channel write pointer register

0x01C1 31D0 RRB_SUB Read ring buffer channel subtraction register

0x01C1 31D4 RRB_RDPTR Read ring buffer channel read pointer register

0x01C1 31D8 PKT_CNT Packet counter value register

0x01C1 31DC - 0x01C1 31FF – Reserved

Table 7-51. TSIF1 Registers

HEX ADDRESS RANGE ACRONYM REGISTER NAME

0x01C1 3400 PID TSIF1 peripheral identification (PID) register

0x01C1 3404 CTRL0 Control register 0 register

0x01C1 3408 CTRL1 Control register 1 register

0x01C1 340C INTEN Interrupt enable register

0x01C1 3410 INTEN_SET Interrupt enable set register

0x01C1 3414 INTEN_CLR Interrupt enable clear register

0x01C1 3418 INTSTAT Interrupt status register

0x01C1 341C INTSTAT_CLR Interrupt status clear register

0x01C1 3420 EMU_CTRL Emulation control register

0x01C1 3424 ASYNC_TX_WAIT Asynchronous transmit wait time register

0x01C1 3428 PAT_SEN_CFG Program association table (PAT) sense configuration register
