000
110
100
101
VIDCLKCTL.VCH2CLK
VP_CLKIN2
GP[4]/STC_CLKIN
VPIF
Channel2
OutputClockSource
VP_CLKIN2
STC_CLKIN
VP_CLKIN0
CRG0_VCXI
URXD2/CRG1_VCXI/GP[39]/CRG0_VCXI
11x
10x
010
SYSCLK8
(B)
PLL
Controller1
VSCLKDIS.VID2
PINMUX0.CRGMUX
001
CRG1_VCXI
VP_CLKIN0
URXD2/CRG1_VCXI/GP[39]/CRG0_VCXI
DEV_MXI/DEV_CLKIN
UCTS2/USD2/CRG0_VCXI/GP[42]/TS1_PTSO
011
AUXCLK
111
(A)
VIDCLKCTL.VCH1CLK
VP_CLKIN1
VP_CLKIN0
VPIF
Channel1
InputClockSource
VP_CLKIN1
VP_CLKIN0
1
0
VSCLKDIS.VID1
TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Figure 7-35. VPIF Capture Channel 1 Source Clock Selection
For both the dual 8-bit or 16-bit display modes, the VPIF Display Channel 2 outputs data synchronous to
VP_CLKO2. The source clock for the VP_CLKO2 output is selectable from a number of external clock
inputs or on-chip clock sources (see Figure 7-36).
(A) 111 = Reserved.
(B) For the -1G device, use an external clock source for the 54-/74.25-/108-/148.5-MHz VPIF clock.
Figure 7-36. VPIF Display Channel 2 Source Clock Selection
For the dual 8-bit display mode, the VPIF Display Channel 3 outputs data synchronous to VP_CLKO3.
The source clock for the VP_CLKO3 output is selectable from a number of external clock inputs or on-chip
clock sources (see Figure 7-37). When the 16-bit display mode for Channel 3 is selected, the clock source
must match that of Channel 2 (VIDCLKCTL.VCH3CLK = VCH2CLK).
