TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 7-43. DQGATE Routing Specification
No. Parameter Min Typ Max Unit
1 DQGATEL Length F
(1)
CKB0B1
2 DQGATEH Length F
(2) (3)
CKB2B3
3 Center to center DQGATE to any other trace spacing 4w
4 DQS/DQ nominal trace length DQLM-50 DQLM DQLM+50 Mils
5 DQGATEL Skew
(4)
100 Mils
6 DQGATEH Skew
(3) (5)
100 Mils
(1) CKB0B1 is the sum of the length of the CK net plus the average length of the DQS0 and DQS1 nets.
(2) CKB2B3 is the sum of the length of the CK net plus the average length of the DQS2 and DQS3 nets.
(3) Only used in 32-bit wide DDR2 memory systems.
(4) Skew from CKB0B1
(5) Skew from CKB2B3
