TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 7-38. Clock Net Class Definitions
Clock Net Class DSP Pin Names
CK DDR_CLK/DDR_CLK
DQS0 DDR_DQS0/DDR_DQS0
DQS1 DDR_DQS1/DDR_DQS1
DQS2
(1)
DDR_DQS2/DDR_DQS2
DQS3
(1)
DDR_DQS3/DDR_DQS3
(1) Only used on 32-bit wide DDR2 memory systems.
Table 7-39. Signal Net Class Definitions
Associated Clock Net
Clock Net Class Class DSP Pin Names
ADDR_CTRL CK DDR_BA[2:0], DDR_A[14:0], DDR_CS, DDR_CAS, DDR_RAS, DDR_WE,
DDR_CKE
DQ0 DQS0 DDR_D[7:0], DDR_DQM0
DQ1 DQS1 DDR_D[15:8], DDR_DQM1
DQ2
(1)
DQS2 DDR_D[23:16], DDR_DQM2
DQ3
(1)
DQS3 DDR_D[31:24], DDR_DQM3
DQGATEL CK, DQS0, DQS1 DDR_DQGATE0, DDR_DQGATE1
DQGATEH
(1)
CK, DQS2, DQS3 DDR_DQGATE2, DDR_DQGATE3
(1) Only used on 32-bit wide DDR2 memory systems.
7.10.2.9 DDR2 Signal Termination
No terminations of any kind are required in order to meet signal integrity and overshoot requirements.
Serial terminators are permitted, if desired, to reduce EMI risk; however, serial terminations are the only
type permitted. Table 7-40 shows the specifications for the series terminators.
Table 7-40. DDR2 Signal Terminations
No. Parameter Min Typ Max Unit
1 CK Net Class
(1)
0 10 Ω
2 ADDR_CTRL Net Class
(1) (2) (3)
0 22 Zo Ω
3 Data Byte Net Classes (DQS0-DQS3, DQ0-DQ3)
(1) (2) (3) (4)
0 22 Zo Ω
4 DQGATE Net Classes (DQGATEL, DQGATEH)
(1) (2) (3)
0 10 Zo Ω
(1) Only series termination is permitted, parallel or SST specifically disallowed.
(2) Terminator values larger than typical only recommended to address EMI issues.
(3) Termination value should be uniform across net class.
(4) When no termination is used on data lines (0 Ωs), the DDR2 devices must be programmed to operate in 60% strength mode.
