TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 7-24. ARM Interrupt Controller Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0x01C4 8000 FIQ0 FIQ Interrupt Status 0 [Interrupt Status of INT[31:0] (If Mapped to FIQ)]
0x01C4 8004 FIQ1 FIQ Interrupt Status 1 [Interrupt Status of INT[63:32] (If Mapped to FIQ)]
0x01C4 8008 IRQ0 IRQ Interrupt Status 0 [Interrupt Status of INT[31:0] (If Mapped to IRQ)]
0x01C4 800C IRQ1 IRQ Interrupt Status 1 [Interrupt Status of INT[63:32] (If Mapped to IRQ)]
0x01C4 8010 FIQENTRY Entry Address [28:0] for Valid FIQ Interrupt
0x01C4 8014 IRQENTRY Entry Address [28:0] for Valid IRQ Interrupt
0x01C4 8018 EINT0 Interrupt Enable Register 0
0x01C4 801C EINT1 Interrupt Enable Register 1
0x01C4 8020 INCTL Interrupt Operation Control Register
0x01C4 8024 EABASE Interrupt Entry Table Base Address Register
0x01C4 8028 - 0x01C4 802F - Reserved
0x01C4 8030 INTPRI0 Interrupt 0-7 Priority Select
0x01C4 8034 INTPRI1 Interrupt 8-15 Priority Select
0x01C4 8038 INTPRI2 Interrupt 16-23 Priority Select
0x01C4 803C INTPRI3 Interrupt 24-31 Priority Select
0x01C4 8040 INTPRI4 Interrupt 32-39 Priority Select
0x01C4 8044 INTPRI5 Interrupt 40-47 Priority Select
0x01C4 8048 INTPRI6 Interrupt 48-55 Priority Select
0x01C4 804C INTPRI7 Interrupt 56-63 Priority Select
0x01C4 8050 - 0x01C4 83FF - Reserved
Copyright © 2009–2012, Texas Instruments Incorporated Peripheral Information and Electrical Specifications 195
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
