• High Group: These pins are high by default, and remain high until configured otherwise by their
respective peripheral (after the peripheral is enabled by the PSC).
PCI_DEVSEL/HCNTL1/EM_BA[1], PCI_FRAME/HINT/EM_BA[0], PCI_STOP/HCNTL0/EM_WE,
PCI_SERR/HDS1/EM_OE, PCI_PERR/HCS/EM_DQM1, PCI_PAR/HAS/EM_DQM0,
PCI_REQ/DMARQ/GP[11]/EM_CS5, PCI_GNT/DMACK/GP[12]/EM_CS4, PCI_CBE3/HR/W/EM_CS3,
PCI_CBE2/HDS2/EM_CS2,
NOTE: For PCI boot mode, all PCI pins now behave according to Z Group.
For more information on the pin behaviors during device-level global reset, see Figure 7-19 and Figure 7-
20 in Section 7.7.9, Reset Electrical Data/Timing.
