TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 7-16. DM6467T EDMA Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0x01C1 0D24 ERREN EDMA3 TC3 Error Enable Register
0x01C1 0D28 ERRCLR EDMA3 TC3 Error Clear Register
0x01C1 0D2C ERRDET EDMA3 TC3 Error Details Register
0x01C1 0D30 ERRCMD EDMA3 TC3 Error Interrupt Command Register
0x01C1 0D34 - 0x01C1 0D3F – Reserved
0x01C1 0D40 RDRATE EDMA3 TC3 Read Command Rate Register
0x01C1 0D44 - 0x01C1 0E3F – Reserved
0x01C1 0E40 SAOPT EDMA3 TC3 Source Active Options Register
0x01C1 0E44 SASRC EDMA3 TC3 Source Active Source Address Register
0x01C1 0E48 SACNT EDMA3 TC3 Source Active Count Register
0x01C1 0E4C SADST EDMA3 TC3 Source Active Destination Address Register
0x01C1 0E50 SABIDX EDMA3 TC3 Source Active B-Index Register
0x01C1 0E54 SAMPPRXY EDMA3 TC3 Source Active Memory Protection Proxy Register
0x01C1 0E58 SACNTRLD EDMA3 TC3 Source Active Count Reload Register
0x01C1 0E5C SASRCBREF EDMA3 TC3 Source Active Source Address B-Reference Register
0x01C1 0E60 SADSTBREF EDMA3 TC3 Source Active Destination Address B-Reference Register
0x01C1 0E64 - 0x01C1 0E7F – Reserved
0x01C1 0E80 DFCNTRLD EDMA3 TC3 Destination FIFO Set Count Reload Register
0x01C1 0E84 DFSRCBREF EDMA3 TC3 Destination FIFO Set Source Address B-Reference Register
EDMA3 TC3 Destination FIFO Set Destination Address B-Reference
0x01C1 0E88 DFDSTBREF
Register
0x01C1 0E8C - 0x01C1 0EFF – Reserved
0x01C1 0F00 DFOPT0 EDMA3 TC3 Destination FIFO Options Register 0
0x01C1 0F04 DFSRC0 EDMA3 TC3 Destination FIFO Source Address Register 0
0x01C1 0F08 DFCNT0 EDMA3 TC3 Destination FIFO Count Register 0
0x01C1 0F0C DFDST0 EDMA3 TC3 Destination FIFO Destination Address Register 0
0x01C1 0F10 DFBIDX0 EDMA3 TC3 Destination FIFO B-Index Register 0
0x01C1 0F14 DFMPPRXY0 EDMA3 TC3 Destination FIFO Memory Protection Proxy Register 0
0x01C1 0F18 - 0x01C1 0F3F – Reserved
0x01C1 0F40 DFOPT1 EDMA3 TC3 Destination FIFO Options Register 1
0x01C1 0F44 DFSRC1 EDMA3 TC3 Destination FIFO Source Address Register 1
0x01C1 0F48 DFCNT1 EDMA3 TC3 Destination FIFO Count Register 1
0x01C1 0F4C DFDST1 EDMA3 TC3 Destination FIFO Destination Address Register 1
0x01C1 0F50 DFBIDX1 EDMA3 TC3 Destination FIFO B-Index Register 1
0x01C1 0F54 DFMPPRXY1 EDMA3 TC3 Destination FIFO Memory Protection Proxy Register 1
0x01C1 0F58 - 0x01C1 0F7F – Reserved
0x01C1 0F80 DFOPT2 EDMA3 TC3 Destination FIFO Options Register 2
0x01C1 0F84 DFSRC2 EDMA3 TC3 Destination FIFO Source Address Register 2
0x01C1 0F88 DFCNT2 EDMA3 TC3 Destination FIFO Count Register 2
0x01C1 0F8C DFDST2 EDMA3 TC3 Destination FIFO Destination Address Register 2
0x01C1 0F90 DFBIDX2 EDMA3 TC3 Destination FIFO B-Index Register 2
0x01C1 0F94 DFMPPRXY2 EDMA3 TC3 Destination FIFO Memory Protection Proxy Register 2
0x01C1 0F98 - 0x01C1 0FBF – Reserved
0x01C1 0FC0 DFOPT3 EDMA3 TC3 Destination FIFO Options Register 3
0x01C1 0FC4 DFSRC3 EDMA3 TC3 Destination FIFO Source Address Register 3
0x01C1 0FC8 DFCNT3 EDMA3 TC3 Destination FIFO Count Register 3
0x01C1 0FCC DFDST3 EDMA3 TC3 Destination FIFO Destination Address Register 3
0x01C1 0FD0 DFBIDX3 EDMA3 TC3 Destination FIFO B-Index Register 3
Copyright © 2009–2012, Texas Instruments Incorporated Peripheral Information and Electrical Specifications 179
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
