TMS320DM6467T
SPRS605C –JULY 2009–REVISED JUNE 2012
www.ti.com
Table 7-16. DM6467T EDMA Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0x01C1 034C DFDST1 EDMA3 TC0 Destination FIFO Destination Address Register 1
0x01C1 0350 DFBIDX1 EDMA3 TC0 Destination FIFO B-Index Register 1
0x01C1 0354 DFMPPRXY1 EDMA3 TC0 Destination FIFO Memory Protection Proxy Register 1
0x01C1 0358 - 0x01C1 037F – Reserved
0x01C1 0380 DFOPT2 EDMA3 TC0 Destination FIFO Options Register 2
0x01C1 0384 DFSRC2 EDMA3 TC0 Destination FIFO Source Address Register 2
0x01C1 0388 DFCNT2 EDMA3 TC0 Destination FIFO Count Register 2
0x01C1 038C DFDST2 EDMA3 TC0 Destination FIFO Destination Address Register 2
0x01C1 0390 DFBIDX2 EDMA3 TC0 Destination FIFO B-Index Register 2
0x01C1 0394 DFMPPRXY2 EDMA3 TC0 Destination FIFO Memory Protection Proxy Register 2
0x01C1 0398 - 0x01C1 03BF – Reserved
0x01C1 03C0 DFOPT3 EDMA3 TC0 Destination FIFO Options Register 3
0x01C1 03C4 DFSRC3 EDMA3 TC0 Destination FIFO Source Address Register 3
0x01C1 03C8 DFCNT3 EDMA3 TC0 Destination FIFO Count Register 3
0x01C1 03CC DFDST3 EDMA3 TC0 Destination FIFO Destination Address Register 3
0x01C1 03D0 DFBIDX3 EDMA3 TC0 Destination FIFO B-Index Register 3
0x01C1 03D4 DFMPPRXY3 EDMA3 TC0 Destination FIFO Memory Protection Proxy Register 3
0x01C1 03D8 - 0x01C1 03FF – Reserved
Transfer Controller 1 Registers
0x01C1 0400 PID Peripheral Identification Register
0x01C1 0404 TCCFG EDMA3 TC1 Configuration Register
0x01C1 0408 - 0x01C1 04FF – Reserved
0x01C1 0500 TCSTAT EDMA3 TC1 Channel Status Register
0x01C1 0504 - 0x01C1 0513 – Reserved
0x01C1 0514 - 0x01C1 051F – Reserved
0x01C1 0520 ERRSTAT EDMA3 TC1 Error Status Register
0x01C1 0524 ERREN EDMA3 TC1 Error Enable Register
0x01C1 0528 ERRCLR EDMA3 TC1 Error Clear Register
0x01C1 052C ERRDET EDMA3 TC1 Error Details Register
0x01C1 0530 ERRCMD EDMA3 TC1 Error Interrupt Command Register
0x01C1 0534 - 0x01C1 053F – Reserved
0x01C1 0540 RDRATE EDMA3 TC1 Read Command Rate Register
0x01C1 0544 - 0x01C1 05FF – Reserved
0x01C1 0600 - 0x01C1 063F – Reserved
0x01C1 0640 SAOPT EDMA3 TC1 Source Active Options Register
0x01C1 0644 SASRC EDMA3 TC1 Source Active Source Address Register
0x01C1 0648 SACNT EDMA3 TC1 Source Active Count Register
0x01C1 064C SADST EDMA3 TC1 Source Active Destination Address Register
0x01C1 0650 SABIDX EDMA3 TC1 Source Active B-Index Register
0x01C1 0654 SAMPPRXY EDMA3 TC1 Source Active Memory Protection Proxy Register
0x01C1 0658 SACNTRLD EDMA3 TC1 Source Active Count Reload Register
0x01C1 065C SASRCBREF EDMA3 TC1 Source Active Source Address B-Reference Register
0x01C1 0660 SADSTBREF EDMA3 TC1 Source Active Destination Address B-Reference Register
0x01C1 0664 - 0x01C1 067F – Reserved
0x01C1 0680 DFCNTRLD EDMA3 TC1 Destination FIFO Set Count Reload Register
0x01C1 0684 DFSRCBREF EDMA3 TC1 Destination FIFO Set Source Address B-Reference Register
EDMA3 TC1 Destination FIFO Set Destination Address B-Reference
0x01C1 0688 DFDSTBREF
Register
176 Peripheral Information and Electrical Specifications Copyright © 2009–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
