TMS320DM6467T
www.ti.com
SPRS605C –JULY 2009–REVISED JUNE 2012
Table 7-16. DM6467T EDMA Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0x01C0 2E8C QEESR QDMA Event Enable Set Register
0x01C0 2E90 QSER QDMA Secondary Event Register
0x01C0 2E94 QSECR QDMA Secondary Event Clear Register
0x01C0 2E98 - 0x01C0 2FFF – Reserved
0x01C0 3000 - 0x01C0 3FFF – Reserved
0x01C0 4000 - 0x01C0 7FFF – Parameter Set RAM (see Table 7-17)
0x01C0 8000 - 0x01C0 FFFF – Reserved
Transfer Controller 0 Registers
0x01C1 0000 PID Peripheral Identification Register
0x01C1 0004 TCCFG EDMA3 TC0 Configuration Register
0x01C1 0008 - 0x01C1 00FF – Reserved
0x01C1 0100 TCSTAT EDMA3 TC0 Channel Status Register
0x01C1 0104 - 0x01C1 0113 – Reserved
0x01C1 0114 - 0x01C1 011F – Reserved
0x01C1 0120 ERRSTAT EDMA3 TC0 Error Status Register
0x01C1 0124 ERREN EDMA3 TC0 Error Enable Register
0x01C1 0128 ERRCLR EDMA3 TC0 Error Clear Register
0x01C1 012C ERRDET EDMA3 TC0 Error Details Register
0x01C1 0130 ERRCMD EDMA3 TC0 Error Interrupt Command Register
0x01C1 0134 - 0x01C1 013F – Reserved
0x01C1 0140 RDRATE EDMA3 TC0 Read Command Rate Register
0x01C1 0144 - 0x01C1 01FF – Reserved
0x01C1 0200 - 0x01C1 023F – Reserved
0x01C1 0240 SAOPT EDMA3 TC0 Source Active Options Register
0x01C1 0244 SASRC EDMA3 TC0 Source Active Source Address Register
0x01C1 0248 SACNT EDMA3 TC0 Source Active Count Register
0x01C1 024C SADST EDMA3 TC0 Source Active Destination Address Register
0x01C1 0250 SABIDX EDMA3 TC0 Source Active B-Index Register
0x01C1 0254 SAMPPRXY EDMA3 TC0 Source Active Memory Protection Proxy Register
0x01C1 0258 SACNTRLD EDMA3 TC0 Source Active Count Reload Register
0x01C1 025C SASRCBREF EDMA3 TC0 Source Active Source Address B-Reference Register
0x01C1 0260 SADSTBREF EDMA3 TC0 Source Active Destination Address B-Reference Register
0x01C1 0264 - 0x01C1 027F – Reserved
0x01C1 0280 DFCNTRLD EDMA3 TC0 Destination FIFO Set Count Reload Register
0x01C1 0284 DFSRCBREF EDMA3 TC0 Destination FIFO Set Source Address B-Reference Register
EDMA3 TC0 Destination FIFO Set Destination Address B-Reference
0x01C1 0288 DFDSTBREF
Register
0x01C1 028C - 0x01C1 02FF – Reserved
0x01C1 0300 DFOPT0 EDMA3 TC0 Destination FIFO Options Register 0
0x01C1 0304 DFSRC0 EDMA3 TC0 Destination FIFO Source Address Register 0
0x01C1 0308 DFCNT0 EDMA3 TC0 Destination FIFO Count Register 0
0x01C1 030C DFDST0 EDMA3 TC0 Destination FIFO Destination Address Register 0
0x01C1 0310 DFBIDX0 EDMA3 TC0 Destination FIFO B-Index Register 0
0x01C1 0314 DFMPPRXY0 EDMA3 TC0 Destination FIFO Memory Protection Proxy Register 0
0x01C1 0318 - 0x01C1 033F – Reserved
0x01C1 0340 DFOPT1 EDMA3 TC0 Destination FIFO Options Register 1
0x01C1 0344 DFSRC1 EDMA3 TC0 Destination FIFO Source Address Register 1
0x01C1 0348 DFCNT1 EDMA3 TC0 Destination FIFO Count Register 1
Copyright © 2009–2012, Texas Instruments Incorporated Peripheral Information and Electrical Specifications 175
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
