Table 7-16. DM6467T EDMA Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0x01C0 2A48 - 0x01C0 2A4F – Reserved
0x01C0 2A50 IER Interrupt Enable Register
0x01C0 2A54 IERH Interrupt Enable Register High
0x01C0 2A58 IECR Interrupt Enable Clear Register
0x01C0 2A5C IECRH Interrupt Enable Clear Register High
0x01C0 2A60 IESR Interrupt Enable Set Register
0x01C0 2A64 IESRH Interrupt Enable Set Register High
0x01C0 2A68 IPR Interrupt Pending Register
0x01C0 2A6C IPRH Interrupt Pending Register High
0x01C0 2A70 ICR Interrupt Clear Register
0x01C0 2A74 ICRH Interrupt Clear Register High
0x01C0 2A78 IEVAL Interrupt Evaluate Register
0x01C0 2A7C - 0x01C0 2A7F – Reserved
0x01C0 2A80 QER QDMA Event Register
0x01C0 2A84 QEER QDMA Event Enable Register
0x01C0 2A88 QEECR QDMA Event Enable Clear Register
0x01C0 2A8C QEESR QDMA Event Enable Set Register
0x01C0 2A90 QSER QDMA Secondary Event Register
0x01C0 2A94 QSECR QDMA Secondary Event Clear Register
0x01C0 2A98 - 0x01C0 2BFF – Reserved
Shadow Region 6 Channel Registers
0x01C0 2C00 ER Event Register
0x01C0 2C04 ERH Event Register High
0x01C0 2C08 ECR Event Clear Register
0x01C0 2C0C ECRH Event Clear Register High
0x01C0 2C10 ESR Event Set Register
0x01C0 2C14 ESRH Event Set Register High
0x01C0 2C18 CER Chained Event Register
0x01C0 2C1C CERH Chained Event Register High
0x01C0 2C20 EER Event Enable Register
0x01C0 2C24 EERH Event Enable Register High
0x01C0 2C28 EECR Event Enable Clear Register
0x01C0 2C2C EECRH Event Enable Clear Register High
0x01C0 2C30 EESR Event Enable Set Register
0x01C0 2C34 EESRH Event Enable Set Register High
0x01C0 2C38 SER Secondary Event Register
0x01C0 2C3C SERH Secondary Event Register High
0x01C0 2C40 SECR Secondary Event Clear Register
0x01C0 2C44 SECRH Secondary Event Clear Register High
0x01C0 2C48 - 0x01C0 2C4F – Reserved
0x01C0 2C50 IER Interrupt Enable Register
0x01C0 2C54 IERH Interrupt Enable Register High
0x01C0 2C58 IECR Interrupt Enable Clear Register
0x01C0 2C5C IECRH Interrupt Enable Clear Register High
0x01C0 2C60 IESR Interrupt Enable Set Register
0x01C0 2C64 IESRH Interrupt Enable Set Register High
0x01C0 2C68 IPR Interrupt Pending Register
